Yamaha StagePas 200 BTR Portable PA System ( StagePas200 BTR / StagePas200BTR )

Description

FEATURES
  • 180 W (HF: 30 W + LF: 150 W) Class-D amplifier
  • 1.4” HF + 8” LF high-quality coaxial compression driver
  • 5-channel digital mixer (3 monaural mic/line + 1 stereo line)
  • Main output multi-band compressor “MODE”
  • 1-knob EQ/preset for each channel
  • High-grade SPX digital reverb (4 program, parameter control), delay, chorus
  • Hi-Z input
  • Equipped with link-out/monitor out
  • Supplied rubber stand allows inclining at 30 or 60 degrees
  • Compatible with audio streaming via Bluetooth
  • Can be controlled remotely via an iOS or Android device using the dedicated STAGEPAS Controller app
  • Optional BTR-STP200 battery included
  • Optional CASE-STP200 carry case for convenient carrying
SPECIFICATIONS
  • Type : 2-way Bi-amp Powered Speaker with mixer
  • Mixing channels : 5 (Mono x3 + Stereo x1)
  • Input channel functions : Hi-Z: CH2/3, 1-knob EQ/Preset: CH1-3/ST
  • Output channel functions : MODE (SPEECH/MUSIC/CLUB)
  • Inputs : Mono x3 (mic/line) + Stereo/Mono x1 (line)
  • Outputs : Monitor/Link out x1
  • Bluetooth : Ver.5.0, A2DP (SBC, AAC), Class 1
  • Control and others : STAGEPAS Controller (iOS/Android app)
  • On-board processors : SPX digital reverb (4 program, parameter control), delay, chorus
  • Speaker type : Coaxial speaker with compression driver
  • Frequency range (-10dB) : 60 Hz – 20 kHz
  • Coverage area : H90? x V90?
  • Crossover : 2.0 kHz
  • Maximum output level (1m; on axis) : 125 dB SPL *1
  • Components : LF : 8" Cone, 2.0" voice coil | HF: 1" throat compression driver, 1.4" voice coil
  • Amplifier class : Class-D
  • Power rating : Dynamic : 180 W (LF: 150 W, HF: 30 W)
  • Cooling : Natural convection (no fan)
  • Power consumption : 10 W (Idle), 20 W (1/8 power)
  • Power requirements : 100-240 V 50/60 Hz, or 29.6 Vdc *2
  • Battery
    - Type : Rechargeable Lithium ion battery pack
    - Capacity : 79.92 Wh (2700 mAh, 29.6 V)
    - Operating Time : Maximum 10 hours, 1/16 power continuous 8 hours
    - Charging Time : Approx. 4 hours
  • Cabinet material : Plastic (ABS)
  • Handle : Top x1
  • Pole socket : ?35 mm x1 (Side)
  • Floor Monitor Angle : 30° or 60°
  • Dimensions (W x H x D) : 300 x 308 x 301 mm (11.8" x 12.1" x 11.9")
  • Weight : 12.5 kg (27.6 lbs) (Including battery)
  • Accessories : Power cord x 1, Battery x 1
Dimension Packaging Weight : 14.0 kg
