Speaker type : 2-way, Bi-amped Powered Speaker, Bass-reflex
-
Frequency range (-10dB) : 53 Hz - 20 kHz
-
Coverage are : H90ﾟ x V60ﾟ
-
Crossover : 1.8 kHz: FIR-X tuning™ (linear phase FIR filter)
-
Maximum Output Level : 132 dB SPL
-
Components : LF : Diameter: 10" cone, Voice Coil: 2.5"
-
Components : HF : Diaphragm: 1.75", Type: 1" throat compression driver
-
Amplifier class : Class-D
-
Power rating : PEAK : 2000 W (LF:1700 W, HF:300 W) *1
-
Power rating : RMS : 1000 W (LF:850 W, HF:150 W) *2
-
Cooling : Fan Cooling, 5 Speeds
-
Power requirements : 100 V - 240 V 50/60 Hz
-
A/D D/A Converters : 32 bit/96 kHz Sampling
-
Processors: HPF: OFF, 50 Hz - 118 Hz, 12 dB - 48 dB/Oct.; DSP-MODE: FOH/MAIN, MONITOR, DJ, LIVE MUSIC, SPEECH, OF
-
I/O connectors : Analog Input : INPUT1: Combo x1, Impedance 20 kΩ (balance) 10kΩ (unbalance), Maximum Input Level +24 dBu; INPUT2: Combo x 1, Impedance 6kΩ (balance) 3 kΩ (unbalance), Maximum Input Level +24 dBu (Line) -6 dBu (Mic)
-
I/O connectors : Analog Output : OUTPUT1: XLR3-32 THRU; OUTPUT2: XLR3-32 THRU or DSP OUT
-
I/O connectors : Bluetooth : Ver.5.0, A2DP (SBC, AAC), Class 1 *3
-
Cabinet material : Plastic (PP)
-
Finish : Black
-
Handle : Top x1
-
Pole socket : Φ35 mm x2 (Bottom, 0° or -7°)
-
Rigging : Top x 2, Rear x 1 (Fit for M8 x 15 mm Eyebolts), Bottom x2, Side x 2 (Fit for M8 x 25 mm UB-DXRDHR10A)
-
Net weight : 49.0 kg (108.0 lbs)
