Wharfedale Pro WLA-28SUBXF - IPX6 Waterproof Line Array Subwoofer Speaker. (WLA28SUBXF WLA 28SUBXF)

Description

IPX6 LINE ARRAY SYSTEM

  • IPX6 Waterproof Line array

  • Wax wrapped components

  • Anti-corrosion stainless steel hardware

  • Waterproof input connectors

  • Plywood construction in aluminium cabinets

  • 2 x 8″ element – WLA-28XF

  • 2 x 15″ flying subwoofer element – WLA-28SUBXF

  • 2 x 18″ subwoofer – WLA-218BXF



FEATURES

  • Dual 15” subwoofer

  • Stainless aluminium hardware

  • Wax wrapped components

  • Flattened front grille

  • Single WY-24K4Z waterproof input connector

  • WY-24K4Z Cable connector included

  • 145 dB Max SPL @ 1 m



SPECIFICATIONS





Model Name

WLA-28SUBXF

System Type

Passive

Configuration

2 x 15″ Subwoofer

Frequency Response (+/- 3dB)

39-900 Hz

Frequency Range (- 10 dB)

35-1.5 KHz

(Passive)Sensitivity 2.83v/1m

108 dB

(Passive)Calculated Maximum SPL @1m

145 dB

System Rated Impedance

4 Ω

Low Frequency Transducer



Size (mm / inches)

381 mm / 15”

Voice Coil Size (mm / inches)

100 mm / 4.0”

LF Magnet Material

ferrite

LF Frame Material

aluminium

Rated Impedance

8 Ω x 2

LF Power re:AES2-2012

600 W x 2

High Frequency Transducer



HF Driver Type:

–

Coil Size (mm / inches)

–

Exit Size (mm / inches)

–

HF Magnet Material

–

Diaphragm Material

–

Rated Impedance

–

HF Power re:AES2-2012

–

Waveguide Type

–

Nominal Coverage (H x V)

–

System Continuous Power (w)

1200 W

System Programme Power (w)

2400 W

System Peak Power (w)

4800 W

Crossover frequency



Hardware

1 x WY-24K4Z  (waterproof)

Rigging

4 points for rigging

pole mount

No

handles

Yes

cabinet type

square

Enclosure Material and finish

18 mm plywood/3.0 mm Aluminium

Colour Options

Waterproof black paint

Grille Material & Finish

3.0 mm Black Aluminium

Dimensions – Unpacked (mm / inches):



Height front

494 mm / 19.4″

Height  Rear

494 mm / 19.4″

Width

845 mm / 33.3″

Depth

653 mm / 25.7″

Dimensions – Packed (mm / inches):



Height

584mm / 23″

Width Front

933mm / 36.7″

Width Rear

933mm / 36.7″

Depth

723mm / 28.5″

Weight



Net Weight (kg / lbs)

81.0kg / 178.2lbs

Gross Weight (kg / lbs)

86.4kg / 190.1lbs
