Wharfedale Pro WLA-218BXF - IPX6 waterproof Line Array Subwoofer (WLA 218BXF WLA218BXF)

Description

FEATURES

  • Dual 18” subwoofer

  • 18mm Plywood construction

  • Wax wrapped components

  • Single WY-24K4Z waterproof input connector

  • WY-24K4Z Cable connector included

  • 148 dB Max SPL @ 1 m



SPECIFICATIONS.





Model Name

WLA-218BXF

System Type

Passive

Configuration

2 x 18″ Subwoofer

Frequency Response (+/- 3dB)

30-800 Hz

Frequency Range (- 10 dB)

25-1.0 KHz

(Passive)Sensitivity 2.83v/1m

109 dB

(Passive)Calculated Maximum SPL @1m

148 dB

System Rated Impedance

4Ω

Low Frequency Transducer



Size (mm / inches)

470 mm / 18”

Voice Coil Size (mm / inches)

102 mm / 4.0”

LF Magnet Material

ferrite

LF Frame Material

aluminium

Rated Impedance

8 Ω x 2

LF Power re:AES2-2012

1000 W x 2

High Frequency Transducer



HF Driver Type:

–

Coil Size (mm / inches)

–

Exit Size (mm / inches)

–

HF Magnet Material

–

Diaphragm Material

–

Rated Impedance

–

HF Power re:AES2-2012

–

Waveguide Type

–

Nominal Coverage (H x V)

–

System Continuous Power (w)

2000 W

System Programme Power (w)

4000 W

System Peak Power (w)

8000 W

Crossover frequency



Hardware

1 x WY-24K4Z  (waterproof)

Rigging



pole mount

No

handles

Yes

cabinet type

square

Enclosure Material and finish

18 mm plywood/3.0 mm Aluminium

Colour Options

Waterproof black paint

Grille Material & Finish

3.0 mm Black Aluminium

Dimensions – Unpacked (mm / inches):



Height front

568 mm / 22.4″

Height  Rear

568 mm / 22.4″

Width

1073 mm / 42.2″

Depth

757 mm / 29.8″

Dimensions – Packed (mm / inches):



Height

644 mm / 25.4″

Width Front

1143 mm / 45.0″

Width Rear

1143 mm / 45.0″

Depth

827 mm / 32.6″

Weight



Net Weight (kg / lbs)

97.0kg / 213.4 lbs

Gross Weight (kg / lbs)

111.0kg / 244.2 lbs
