RM11,980.00 RM0.00
FEATURES 21″ Beyma driver 1600 W Continuous 3200 W Programme 6400 W Peak 4.0″ Quattro LF voice coil (4 layers) 147 dB System Peak SPL SPECIFICATIONS Model Name WLA-121SUB Design Subwoofer System Type 21″ Subwoofer Configuration Single Subwoofer Frequency Response (+/-3 dB) 25 Hz – 100Hz... Read more
SKU: WLA121SUB
FEATURES
21″ Beyma driver
1600 W Continuous
3200 W Programme
6400 W Peak
4.0″ Quattro LF voice coil (4 layers)
147 dB System Peak SPL
SPECIFICATIONS
Model Name |
WLA-121SUB |
Design |
Subwoofer |
System Type |
21″ Subwoofer |
Configuration |
Single Subwoofer |
Frequency Response (+/-3 dB) |
25 Hz – 100Hz |
Frequency Range (- 10 dB) |
18 Hz – 125 Hz |
Sensitivity 2.83 V/1 m |
103 dB* |
Calculated Maximum SPL @ 1 m |
141 dB* |
System Peak SPL |
147 dB** |
System Rated Impedance |
4 Ω |
* |
level at 1 m under half space conditions using pink noise with crest factor 2, with dedicated preset. |
** |
level at 1 m under free field conditions using pink noise with crest factor 4, with dedicated preset. |
Low Frequency Transducer |
|
Size |
545 mm / 21″ |
Voice Coil Size |
101.6 mm / 4.0″ QUATTRO (4 layers) |
LF Frame Material |
Aluminium |
High Frequency Transducer |
|
HF Driver Type |
/ |
Coil Size (mm / inches) |
/ |
Exit Size (mm / inches) |
/ |
Diaphragm Material |
/ |
Waveguide Type |
/ |
Nominal Coverage (HxV) |
/ |
Special Features |
Aluminium demodulating ring |
|
Waterproof LF cone |
|
Malt Cross® TCS |
Power(AES2) |
|
System Continuous Power (W) |
1600 |
System Programme Power (W) |
3200 |
System Peak Power (W) |
6400 |
Crossover Frequency |
100 Hz |
Recommended HPF = BW 18 dB/oct. |
20 Hz |
Input Connector |
2 x speakON compatible |
Rigging & Hardware: |
3 points for rigging |
Vertical Splay angle range: |
/ |
Horizontal Splay angle |
/ |
Optional Accessories |
WLA-1 Common Fly Frame |
Hardware |
– |
Stand pole: |
M20 Pole mount |
Handles: |
2 side（4 pcs) + 2 (top / bottom) |
Enclosure |
|
Cabinet Type |
Rectangular |
Enclosure Material and finish |
18 mm plywood / Rhino Rock |
Colour |
Black paint |
Grille Material & Finish |
Powder coated perforated steel |
Dimensions – Unpacked: |
|
Height Front |
820 mm / 32.3″ |
Height Rear |
/ |
Width |
566 mm / 23.4″ |
Depth |
760 mm / 29.9″ |
Dimensions – Packed: |
|
Height |
895 mm / 35.2″ |
Width Front |
656 mm / 25.8″ |
Width Rear |
/ |
Depth |
850 mm / 33.5″ |
Weight |
|
Net Weight |
70.5 Kg |
Gross Weight |
76.5 Kg |
