WHARFEDALE PRO TYPHON-AX15BT Series 770 Watts RMS 15" 2-Way Loudspeaker with Bluetooth - Each / Pair (AX15 BT AX15-BT)

Description

The Typhon series are powerful, portable and versatile active loudspeakers available as a 15”, 12” or highly portable 8” model. Suitable for many professional audio applications a Typhon is ideal for DJ’s, live bands, small to medium size stages, installations and houses of worship.



Key Features

●15″ Bi-amplified active loudspeaker

  • 1.75″ HF compression driver

  • 770 w Continuous

  • 1540 w Peak

  • 130 dB Max SPL @ 1 meter

  • Huge 3.0″ LF voice coil

  • Bluetooth Input



SPECIFICATIONS





Model Name

Typhon-AX15-BT

System Type

Active 15″ 2-way

Frequency Response (+/-3 dB)

45 Hz-20 KHz

Frequency Range (-10 dB)

40 Hz-20 KHz

Maximum SPL (peak @1 m)

130 dB

Sensitivity (@ 1 W / 1 m)

99 dB

Low Frequency Transducer



Size (mm / inches)

381 mm / 15″

Voice-Coil Size (mm / inches)

75 mm / 3.0″

Rated Impedance

4 Ω

High Frequency Transducer



HF Driver Type:

Compression Driver

Coil Size (mm / inches)

44 mm / 1.75″

Exit Size (mm / inches)

25 mm / 1″

Diaphragm Material

Titanium

Rated Impedance

8 Ω

Nominal Coverage (H x V)

Hybrid Symmetry Horn

100° x 80°

Amplifiers

2 x Class D

Power Rating:

1540 W Peak (1300 W LF +

240 W HF), 770 W Continuous

(650 W LF + 120 W HF)





DSP Controls—D-EQ

FLAT/MONITOR/BASS/PUNCH

Amplifier Protection



Power On Protection

Yes

Thermal Protection

Yes

Low Line Voltage Shut Down

Yes

Driver Protection

Yes

DC Protection

Yes

Short Protection

Yes

Clip Limiter

Yes

Limiter Indicator

Yes

Power Indicator

Yes

Inputs



Input A – type

Balanced/Bluetooth (aptX with link Stereo)

Input Sensitivity

775 mV(0 dBu)

Maximum Input Level

4 V

Input Connector

2 x XLR, 2 x 6.3 mm jack (Line/MIC)

Input Impedance

20 K ohms

Line Output



Line Output Connector

XLR

Loop Gain

0 dB

AC Power details



Power Supply

220~240 V AC/100~120 V AC 50/60 Hz

Rigging / Bracket / Mounting Options

9 x M8 threaded inserts



Pole-mount receptacle with lock screw



Optional WPB-2 wall-mount bracket

Handles

2 carry handles (on top and bottom side)

Enclosure



Enclosure Material and finish

Injection Moulded Polypropylene

Colour Options

Black paint

Grille Material & Finish

steel

Dimensions – Unpacked



Height

697.7 mm / 27.5″

Width Front

480 mm / 18.9″

Width Rear

186.2 mm / 7.3″

Depth

400 mm / 15.7″

Dimensions – Packed



Height

788 mm / 31.02″

Width Front

550 mm / 21.9″

Width Rear

550 mm / 21.9″

Depth

475 mm / 18.7″

Net Weight (kg / lbs)

27.3 kg / 60.06 lbs

Gross Weight (kg / lbs)

30.0 kg / 66 lbs



WHARFEDALE PRO TYPHON-AX15BT Series 770 Watts RMS 15" 2-Way Loudspeaker with Bluetooth - Each / Pair (AX15 BT AX15-BT)

Product form

RM3,790.00  RM3,411.00 Sale 10%

WALK-IN INSTALLMENT PLAN UP TO 36 MONTHS
RHB Bank
Aeon Bank
UOB Bank
Affin Bank
Ambank
HSBC Bank
OCBC Bank
Standard Chartered
BSN
Alliance Bank
Maybank
Public Bank
Found Better Price? Reach us Now.
Click here if you find a better price.
Free pickup in our shop(s)

SKU: AX15BT-Each

    Same Day Delivery via Lalamove

    Description

    The Typhon series are powerful, portable and versatile active loudspeakers available as a 15”, 12” or highly portable 8” model. Suitable for many professional audio applications a Typhon is ideal for DJ’s, live bands, small to medium size stages, installations and houses of worship.



    Key Features

    ●15″ Bi-amplified active loudspeaker

    • 1.75″ HF compression driver

    • 770 w Continuous

    • 1540 w Peak

    • 130 dB Max SPL @ 1 meter

    • Huge 3.0″ LF voice coil

    • Bluetooth Input



    SPECIFICATIONS





    Model Name

    Typhon-AX15-BT

    System Type

    Active 15″ 2-way

    Frequency Response (+/-3 dB)

    45 Hz-20 KHz

    Frequency Range (-10 dB)

    40 Hz-20 KHz

    Maximum SPL (peak @1 m)

    130 dB

    Sensitivity (@ 1 W / 1 m)

    99 dB

    Low Frequency Transducer



    Size (mm / inches)

    381 mm / 15″

    Voice-Coil Size (mm / inches)

    75 mm / 3.0″

    Rated Impedance

    4 Ω

    High Frequency Transducer



    HF Driver Type:

    Compression Driver

    Coil Size (mm / inches)

    44 mm / 1.75″

    Exit Size (mm / inches)

    25 mm / 1″

    Diaphragm Material

    Titanium

    Rated Impedance

    8 Ω

    Nominal Coverage (H x V)

    Hybrid Symmetry Horn

    100° x 80°

    Amplifiers

    2 x Class D

    Power Rating:

    1540 W Peak (1300 W LF +

    240 W HF), 770 W Continuous

    (650 W LF + 120 W HF)





    DSP Controls—D-EQ

    FLAT/MONITOR/BASS/PUNCH

    Amplifier Protection



    Power On Protection

    Yes

    Thermal Protection

    Yes

    Low Line Voltage Shut Down

    Yes

    Driver Protection

    Yes

    DC Protection

    Yes

    Short Protection

    Yes

    Clip Limiter

    Yes

    Limiter Indicator

    Yes

    Power Indicator

    Yes

    Inputs



    Input A – type

    Balanced/Bluetooth (aptX with link Stereo)

    Input Sensitivity

    775 mV(0 dBu)

    Maximum Input Level

    4 V

    Input Connector

    2 x XLR, 2 x 6.3 mm jack (Line/MIC)

    Input Impedance

    20 K ohms

    Line Output



    Line Output Connector

    XLR

    Loop Gain

    0 dB

    AC Power details



    Power Supply

    220~240 V AC/100~120 V AC 50/60 Hz

    Rigging / Bracket / Mounting Options

    9 x M8 threaded inserts



    Pole-mount receptacle with lock screw



    Optional WPB-2 wall-mount bracket

    Handles

    2 carry handles (on top and bottom side)

    Enclosure



    Enclosure Material and finish

    Injection Moulded Polypropylene

    Colour Options

    Black paint

    Grille Material & Finish

    steel

    Dimensions – Unpacked



    Height

    697.7 mm / 27.5″

    Width Front

    480 mm / 18.9″

    Width Rear

    186.2 mm / 7.3″

    Depth

    400 mm / 15.7″

    Dimensions – Packed



    Height

    788 mm / 31.02″

    Width Front

    550 mm / 21.9″

    Width Rear

    550 mm / 21.9″

    Depth

    475 mm / 18.7″

    Net Weight (kg / lbs)

    27.3 kg / 60.06 lbs

    Gross Weight (kg / lbs)

    30.0 kg / 66 lbs
