WHARFEDALE PRO TYPHON-AX12BT Series 720 Watts RMS12" 2-Way Loudspeaker with Bluetooth - Each / Pair (AX12 BT AX12-BT)

Description

The Typhon series are powerful, portable and versatile active loudspeakers available as a 15”, 12” or highly portable 8” model. Suitable for many professional audio applications a Typhon is ideal for DJ’s, live bands, small to medium size stages, installations and houses of worship.



Key Features

●12″ Bi-amplified active loudspeaker

  • 1.75″ HF compression driver

  • 720 w Continuous

  • 1440 w Peak

  • 129 dB Max SPL @ 1 meter

  • 2.5″ LF voice coil

  • Bluetooth Input



SPECIFICATIONS





Model Name

Typhon-AX12-BT

System Type

Active 12″ 2-way

Frequency Response (+/-3 dB)

55 Hz-20 KHz

Frequency Range (-10 dB)

50 Hz-20 KHz

Maximum SPL (peak @1 m)

129 dB

Sensitivity (@ 1 W / 1 m)

98 dB

Low Frequency Transducer



Size (mm / inches)

305 mm / 12″

Voice-Coil Size (mm / inches)

65 mm / 2.5”

Rated Impedance

4 Ω

High Frequency Transducer



HF Driver Type:

Compression Driver

Coil Size (mm / inches)

44 mm / 1.75″

Exit Size (mm / inches)

25 mm / 1″

Diaphragm Material

Titanium

Rated Impedance

8 Ω

Nominal Coverage (H x V)

Hybrid Symmetry Horn

100°x80°

Amplifiers

2 x Class D

Power Rating:

1440 W Peak (1200 W LF +

240 W HF), 720 W Continuous

(600 W LF + 120 W HF)





DSP Controls—D-EQ

FLAT/MONITOR/BASS/PUNCH

Amplifier Protection



Power On Protection

Yes

Thermal Protection

Yes

Low Line Voltage Shut Down

Yes

Driver Protection

Yes

DC Protection

Yes

Short Protection

Yes

Clip Limiter

Yes

Limiter Indicator

Yes

Power Indicator

Yes

Inputs



Input A – type

Balanced/Bluetooth(aptX,with link Stereo)

Input Sensitivity

775 mV (0 dBu)

Maximum Input Level

4 V

Input Connector

2 x XLR, 2 x 6.3 mm (Line/MIC)

Input Impedance

20 K ohms

Line Output



Line Output Connector

XLR

Loop Gain

0 dB

AC Power details



Power Supply

220~240 VAC / 100~120 VAC 50/60 Hz

Rigging / Bracket / Mounting Options

9 x M8 threaded inserts



Pole-mount receptacle with lock screw



Optional WPB-2 wall-mount bracket

Handles

4 carry handles (on top and bottom side)

Enclosure



Enclosure Material and finish

Injection Moulded Polypropylene

Colour Options

Black paint

Grille Material & Finish

steel

Dimensions – Unpacked



Height

558 mm / 22.0″

Width Front

344 mm / 13.6″

Width Rear

245 mm / 9.6″

Depth

340 mm / 13.4″

Dimensions – Packed



Height

645 mm / 25.4″

Width Front

425 mm / 16.7″

Width Rear

425 mm / 16.7″

Depth

419 mm / 16.5″

Net Weight (kg / lbs)

16.2 kg / 35.6 lbs

Gross Weight (kg / lbs)

18.9 kg / 41.6 lbs
