Wharfedale Pro Sigma X8 Passive Two-Way Speaker, Each / Pair - Black (SIGMA-X8/SIGMAX8)

Description

All SIGMA-X models (with the exception of the 70 V / 100 V T models) are equipped with both speakON and barrier strip inputs.  It is another small step that makes the installation easy.



Key Features

●150 W AES (Continuous)

  • 300 W Programme

  • 600 W Peak

  • 124 dB Max SPL @ 1 m



SPECIFICATIONS





Model Name

SIGMA-X8

System Type

Passive

Configuration

Two-Way

Frequency Response (+/-3 dB)

70 Hz – 18 KHz

Frequency Range (-10 dB)

65 Hz – 20 KHz

Sensitivity 2.83 V / 1 m

96 dB

Calculated Maximum SPL @1 m

124 dB

System Rated Impedance

8 Ω

Low Frequency Transducer



Size (mm / inches)

203 mm / 8”

Voice Coil Size (mm / inches)

38 mm / 1.5”

Rated Impedance

8 Ω

LF Power re:AES2-2012

150 W

High Frequency Transducer



HF Driver Type

Compression Driver

Coil Size (mm / inches)

44 mm / 1.75”

Exit Size (mm / inches)

1″

Diaphragm Material

Titanium

Rated Impedance

8 Ω

HF Power re:AES2-2012

40 W

Waveguide Type

Constant Directivity /

Rotatable

Nominal Coverage (H x V)

90˚ x 60˚

LF Driver

1 x 8″

HF Driver

1 x 1.75″ Titanium Compression Driver

Power



System Continuous Power

150 W

System Programme Power

300 W

System Peak Power

600 W

Crossover frequency

2.8 KHz

Recommended HPF

= BW 18 dB/oct.

55 Hz

Input Connector

2 x speakON / 1x Barrier Strip

Hardware

35 mm pole socket



M8 x 17



1 handle on back

Enclosure



Enclosure Material

15 mm MDF

Finish

Black Paint / White Paint

Grille Material & Finish

1.2 mm steel, painted

Dimensions – Unpacked



Height

465 mm / 18.3″

Width Front

284 mm / 11.2″

Width Rear

176 mm / 6.9″

Depth

282.7 mm / 11.1″

Dimensions – Packed



Height

505 mm / 19.9″

Width Front

364 mm / 14.3″

Width Rear

214.4 mm / 8.43″

Depth

333 mm / 13.1″

Weight



Net Weight

12.2 kg / 26.8 lbs

Gross Weight

13.5 kg / 29.7 lbs

Optional Wall-mount bracket

WPB-1 / WPB-2
