WHARFEDALE PRO SIGMA-X15 1400W PEAK 15" 2-WAY INSTALLATION LOUDSPEAKER, Each /Pair - BLACK (SIGMA X15/SIGMAX15)

Description

All SIGMA-X models (with the exception of the 70 V / 100 V T models) are equipped with both speakON and barrier strip inputs.  It is another small step that makes the installation easy.



Key Features

●350 W AES (Continuous)

  • 700 W Programme

  • 1400 W Peak

  • 129 dB Max SPL @ 1 m



SPECIFICATIONS







Model Name

SIGMA-X15

System Type

Passive

Configuration

Two-Way

Frequency Response (+/-3 dB)

50 Hz – 18 KHz

Frequency Range (-10 dB)

45 Hz – 20 KHz

Sensitivity 2.83 V / 1 m

98 dB

Calculated Maximum SPL @1 m

129 dB

System Rated Impedance

8 Ω

Low Frequency Transducer



Size (mm / inches)

381 mm / 15”

Voice Coil Size (mm / inches)

64 mm / 2.5”

Rated Impedance

8 Ω

LF Power re:AES2-2012

350 W

High Frequency Transducer



HF Driver Type

Compression Driver

Coil Size (mm / inches)

44 mm / 1.75”

Exit Size (mm / inches)

1″

Diaphragm Material

Titanium

Rated Impedance

8 Ω

HF Power re:AES2-2012

40 W

Waveguide Type

Constant Directivity /

Rotatable

Nominal Coverage (H x V)

90˚ x 60˚

LF Driver

1 x 15″

HF Driver

1 x 1.75″ Titanium Compression Driver

Power



System Continuous Power

350 W

System Programme Power

700 W

System Peak Power

1400 W

Crossover frequency

2.2 KHz

Recommended HPF

= BW 18 dB/oct.

33 Hz

Input Connector

2 x speakON / 1x Barrier Strip

Hardware

Dual-angle (0° / 10°) 35 mm socket



M8 x 17



2 handles on sides

Enclosure



Enclosure Material

15 mm MDF

Finish

Black Paint / White Paint

Grille Material & Finish

1.2 mm steel, painted

Dimensions – Unpacked



Height

650 mm / 25.6″

Width Front

435 mm / 17″

Width Rear

261 mm / 11.7″

Depth

439 mm / 17.25″

Dimensions – Packed



Height

715 mm / 28.1″

Width Front

553 mm / 21.75″

Width Rear

304 mm / 12″

Depth

488 mm / 19.2″

Weight



Net Weight

24.4 kg / 53.7 lbs

Gross Weight

27.7 kg / 60.9 lbs

Optional Wall-mount bracket

WPB-1 / WPB-2
