WHARFEDALE PRO SIGMA-X10 800W PEAK 10" 2-WAY INSTALLATION LOUDSPEAKER, Each / Pair -WHITE (SIGMA X10/SIGMAX10)

Description

All SIGMA-X models (with the exception of the 70 V / 100 V T models) are equipped with both speakON and barrier strip inputs.  It is another small step that makes the installation easy.



Key Features

●200 W AES (Continuous)

  • 400 W Programme

  • 800 W Peak

  • 126 dB Max SPL @ 1 m



SPECIFICATIONS





Model Name

SIGMA-X10

System Type

Passive

Configuration

Two-Way

Frequency Response (+/-3 dB)

65 Hz – 18 KHz

Frequency Range (-10 dB)

60 Hz – 20 KHz

Sensitivity 2.83 V / 1 m

97 dB

Calculated Maximum SPL @1 m

126 dB

System Rated Impedance

8 Ω

Low Frequency Transducer



Size (mm / inches)

254 mm / 10”

Voice Coil Size (mm / inches)

38 mm / 1.5”

Rated Impedance

8 Ω

LF Power re:AES2-2012

200 W

High Frequency Transducer



HF Driver Type

Compression Driver

Coil Size (mm / inches)

44 mm / 1.75”

Exit Size (mm / inches)

1″

Diaphragm Material

Titanium

Rated Impedance

8 Ω

HF Power re:AES2-2012

40 W

Waveguide Type

Constant Directivity /

Rotatable

Nominal Coverage (H x V)

90˚ x 60˚

LF Driver

1 x 10″

HF Driver

1 x 1.75″ Titanium Compression Driver

Power



System Continuous Power

200 W

System Programme Power

400 W

System Peak Power

800 W

Crossover frequency

2.4 KHz

Recommended HPF

= BW 18 dB/oct.

45 Hz

Input Connector

2 x speakON / 1x Barrier Strip

Hardware

Dual-angle (0° /10°) 35 mm socket



M8 x 17



1 handle on back

Enclosure



Enclosure Material

15 mm MDF

Finish

Black Paint / White Paint

Grille Material & Finish

1.2 mm steel, painted

Dimensions – Unpacked



Height

520 mm / 20.5″

Width Front

338 mm / 13.3″

Width Rear

213 mm / 8.4″

Depth

338.3 mm / 13.3″

Dimensions – Packed



Height

585 mm / 23″

Width Front

441 mm / 17.3″

Width Rear

251 mm / 9.9″

Depth

389 mm / 15.3″

Weight



Net Weight

17.1 kg / 37.62 lbs

Gross Weight

18.8 kg / 41.4 lbs

Optional Wall-mount bracket

WPB-1 / WPB-2



WHARFEDALE PRO SIGMA-X10 800W PEAK 10" 2-WAY INSTALLATION LOUDSPEAKER, Each / Pair -WHITE (SIGMA X10/SIGMAX10)

Product form

RM1,720.00  RM1,548.00 Sale 10%

WALK-IN INSTALLMENT PLAN UP TO 36 MONTHS
RHB Bank
Aeon Bank
UOB Bank
Affin Bank
Ambank
HSBC Bank
OCBC Bank
Standard Chartered
BSN
Alliance Bank
Maybank
Public Bank
Found Better Price? Reach us Now.
Click here if you find a better price.
Free pickup in our shop(s)

SKU: SIGMA-X10WH-EACH

    Same Day Delivery via Lalamove

    Description

    All SIGMA-X models (with the exception of the 70 V / 100 V T models) are equipped with both speakON and barrier strip inputs.  It is another small step that makes the installation easy.



    Key Features

    ●200 W AES (Continuous)

    • 400 W Programme

    • 800 W Peak

    • 126 dB Max SPL @ 1 m



    SPECIFICATIONS





    Model Name

    SIGMA-X10

    System Type

    Passive

    Configuration

    Two-Way

    Frequency Response (+/-3 dB)

    65 Hz – 18 KHz

    Frequency Range (-10 dB)

    60 Hz – 20 KHz

    Sensitivity 2.83 V / 1 m

    97 dB

    Calculated Maximum SPL @1 m

    126 dB

    System Rated Impedance

    8 Ω

    Low Frequency Transducer



    Size (mm / inches)

    254 mm / 10”

    Voice Coil Size (mm / inches)

    38 mm / 1.5”

    Rated Impedance

    8 Ω

    LF Power re:AES2-2012

    200 W

    High Frequency Transducer



    HF Driver Type

    Compression Driver

    Coil Size (mm / inches)

    44 mm / 1.75”

    Exit Size (mm / inches)

    1″

    Diaphragm Material

    Titanium

    Rated Impedance

    8 Ω

    HF Power re:AES2-2012

    40 W

    Waveguide Type

    Constant Directivity /

    Rotatable

    Nominal Coverage (H x V)

    90˚ x 60˚

    LF Driver

    1 x 10″

    HF Driver

    1 x 1.75″ Titanium Compression Driver

    Power



    System Continuous Power

    200 W

    System Programme Power

    400 W

    System Peak Power

    800 W

    Crossover frequency

    2.4 KHz

    Recommended HPF

    = BW 18 dB/oct.

    45 Hz

    Input Connector

    2 x speakON / 1x Barrier Strip

    Hardware

    Dual-angle (0° /10°) 35 mm socket



    M8 x 17



    1 handle on back

    Enclosure



    Enclosure Material

    15 mm MDF

    Finish

    Black Paint / White Paint

    Grille Material & Finish

    1.2 mm steel, painted

    Dimensions – Unpacked



    Height

    520 mm / 20.5″

    Width Front

    338 mm / 13.3″

    Width Rear

    213 mm / 8.4″

    Depth

    338.3 mm / 13.3″

    Dimensions – Packed



    Height

    585 mm / 23″

    Width Front

    441 mm / 17.3″

    Width Rear

    251 mm / 9.9″

    Depth

    389 mm / 15.3″

    Weight



    Net Weight

    17.1 kg / 37.62 lbs

    Gross Weight

    18.8 kg / 41.4 lbs

    Optional Wall-mount bracket

    WPB-1 / WPB-2
