TWS BLUETOOTH
Using the BT Stereo link mode, 2 units of Diamond Studio BT create their own Stereo linked pair.
Diamond Studio BT use TWS (True Wireless Stereo) technology to create a controllable linked pair of speakers from a
single Bluetooth input.
Key Features
SPECIFICATIONS
Model Name |
Diamond Studio 5-BT |
System Type |
Active 5” 2-way Bi-Amplified |
Freq. Range (-10 dB) Analog Input |
45 Hz-25 KHz |
Maximum SPL (peak @1 m) |
110 dB |
LF Transducer |
5″ Fiberglass composite woofer |
HF Transducer |
Silk Soft dome tweeter |
Coil Size (mm / inches) |
25.4 mm / 1” |
High Frequency Coverage (H x V) |
135° x 110° |
Total Power Amplifiers |
140 W |
Low-Frequency Power Amplifier (Class D) |
80 W Continuous / 160 W Peak |
High- Frequency Power Amplifier (Class D ) |
60 W Continuous / 120 W Peak |
Electronic Crossover: |
|
Crossover Frequency |
2.2 KHz |
Controls |
|
Equalization (dB) |
HF / LF Level Adjust (-2, 0, +1 ,+2) |
System Volume |
-∞ to +10 dB |
Amplifier Protection |
Yes |
Power On Protection |
Power switch on / off mute |
Thermal Protection |
Amplifier shutdown, auto reset |
Driver, DC and Short Protection |
Yes |
Limiter Indicator |
Red LED |
Power Indicator |
Green LED/white LED (LOGO) |
Input type |
Balanced / Unbalanced / Bluetooth |
Input Connectors |
TRS JACK / FEMALE XLR/RCA |
AC Power Options |
100 V-240 V |
Power On Indicator |
LED |
Cabinet Material |
MDF |
Cabinet Colour |
black |
Dimensions (Unpacked): |
|
Height |
290 mm /11.42 in |
Width |
180 mm /7.1 in |
Depth |
240 mm /9.45 in |
Dimensions (packed): |
|
Height |
350 mm / 13.78 in |
Width |
242.5 mm / 9.55 in |
Depth |
303 mm / 11.93 in |
Weight |
|
Net Weight |
5.62 kg /12.4 lbs |
Gross Weight |
6.47 kg / 14.2 lbs |
