Description
SAME DAY DELIVERY / INSTALLATION SERVICE & SELF PICKUP WITHIN KLANG VALLEY / KL AREA
- Please select shipping option 'Own Courier' for same day delivery / self-collect at showroom
- Third party pickup charges to be beared by buyer
- Kindly put a remark for self collection / Lalamove in your order
- installation request (Piano and Drum) which is available within Klang Valley / KL area (Additional Charges)
EAST MALAYSIA ORDERS
- Sea Shipping will be arranged for bulky items, usually takes 3-4 weeks time
FOR STANDARD DELIVERY
Please select shipping option 'Standard Delivery' and all orders will be shipped out on timely manner.
*Kindly take note that the courier services are beyond our control, estimated delivery time is around 2-7 working days
Waze: Live Music Centre
No 20 & 20-1 & 22 & 22A,
Jalan BRP 1/6, Bukit Rahman Putra, 47000 Sungai Buloh, Selangor
Contact : 0-1-6-5-2-0-1-0-6-6
FEATURES
✪ All-new dual-footswitch pedal-format multi-effects processor/ SnapTone & IR loader
✪ Over 100 high-quality effects
✪ Supports loading 3rd-party cabinet IRs, max 20 stored
✪ Supports loading NAM (Neural Amp Modeler), with 50 curated files, max 80 stored
✪ 100 patch slots (55 factory patches)
✪ Up to 9 modules able to work simultaneously, with the order of some modules being customizable
✪ Convenient Knob-and-Button Controls
✪ Comprehensively Redesigned Interface with Full-Functionality Coverage
✪ Supports expression pedals and external footswitches
✪ Two bypass modes available: analog bypass and digital bypass
✪ Dual 1/4″ TS unbalanced stereo output jacks
✪ 2-in/2-out USB Audio, supporting re-amp and compatible with Win/Mac/iOS/Android systems
✪ Supports USB MIDI and features dual 1/8″ TRS jacks for MIDI input & thru functionality
✪ Supports BT wireless audio playback and can record via the USB Audio
✪ Supports connection to iOS/Android edit/manage app featuring 100 drum patterns
✪ Intuitive Win/Mac software for file management & firmware updates
✪ Compact and robust metal casing
✪ Supports power supply by built-in battery
✪ DC 9V or USB 5V power supply & charging
SPECIFICATIONS
A/D/A Converter: 24-bit high-performance audio
Sampling Frequency: 44.1 kHz
SNR: 106 dB
Module: 9 modules can be used simultaneously
Patch Memory: 100 Patch slots, 55 Factory Patches
BT Wireless: 5.0 Dual-Mode (BLE & audio)
Analog Input Connection
Input: 1/4″ unbalanced (TS)
Input Impedance: 1 MOhms
EXP/FS: 1/4″ (TRS)
Analog Output Connection
Output (L/R): 1/4″ unbalanced stereo (TS)
Output Impedance: 100 Ohms
Phones Output: 1/8″ stereo (TRS), 22 Ohms
Digital Connection
USB Port: USB 2.0 Type-C Port
MIDI IN: 1/8″ (TRS)
MIDI THRU: 1/8″ (TRS)
Size and Weight
Dimensions: 122 mm (W) × 82 mm (D) × 54 mm (H)
Unit Weight: 430 g
Battery
Capacity: 1450 mAh
Charging: Both DC 9V and USB Inputs Support Battery Charging
Power
Power Requirements: DC 9V center negative or USB 5V
Current Consumption: 500 mA (DC 9V) or 1A (USB 5V)
