SPECIFICATIONS

• Power Source
• 100 - 240 V AC, 50/60Hz
• Rated Output
• 240 W
• Power/Current Consumption
• 314 W (Rated output), 70 W (based on EN62368),
• 200 mA or less (when power switch is OFF)
• Frequency Response
• 50 Hz - 20 kHz ±3 dB (1/8 rated output)
• Distortion
• 1 % or less at 1 kHz, rated power (20 kHz LPF (AUX-0025))
• Tone Control
• Bass: ±10 dB at 100 Hz
• Treble: ±10 dB at 10 kHz
• S/N Ratio
• 88 dB or more (Master volume: min.)
• 76 dB or more (Master volume: max.)
• 55 dB or more (INPUT 1 - 6)
• 72 dB or more (INPUT 7)
• (A-weighted)
• Audio Input
• INPUT 1, 2: -60 dB(*¹)(MIC) / -20 dB (*¹) (LINE) selectable, 600 O, electronically-balanced, removable terminal block (3 pins)
• Note: MIC inputs are equipped with phantom power (24V DC, ON/OFF switchable)
• INPUT 3, 4: -60 dB(*¹), 600 O, electronically-balanced, removable terminal block (3 pins)
• Note: MIC inputs are equipped with phantom power (24V DC, ON/OFF switchable)
• INPUT 5, 6: MIC (BUS 1) / LINE (BUS 2) selectable
•  MIC : -60 dB(*¹), 600 O, electronically-balanced, removable terminal block (3 pins)
•  LINE: -20 dB (*¹), 10 kO, unbalanced, RCA pin jack x 2
• INPUT 7: -20 dB(*¹), 10 kO, unbalanced, RCA pin jack x 2
• PWR AMP IN: 0 dB (*1), 600 O, unbalanced, RCA pin jack
• Input Bus
• INPUT 1 - 4: BUS 1
• INPUT 5 - 6: BUS 1/BUS 2 selectable
• INPUT 7: BUS 2
• Audio Output
• Speaker out: Low impedance (4 - 16 O) /
•                     High impedance (DIRECT, ZONE 1, ZONE 2: 100 V / total 42 O), removable terminal block (6 pins)
•                     (ZONE 1 / ZONE 2 is selectable, max. 240 W per output)
• Rec out: 0 dB(*¹), 600 O, unbalanced, RCA pin jack
• Line out 1, 2: 0 dB (*¹) , 600 O, unbalanced, RCA pin jack (Interlock with zone selection is possible)
• Control Input
• 4 channels. no-voltage make contact input, open voltage: 35 V DC or less,
• Short circuit current: 10 mA or less, removable terminal block (4 pins)
• REMOTE VOLUME: Removable terminal block (4 pins)
• ZONE CONTROL IN: No-voltage make contact input, even voltage: 35 V DC or less,
• short-circuit current: 10 mA or less, removable terminal block (4 pins)
• Control Output
• POWER REMOTE OUT: Open collector output, withstand voltage: 30 V DC or less, control current: 25 mA or less, removable terminal block (4 pins)
• EMERGENCY OUT: Open collector output, withstand voltage 30 V DC or less, control current: 25 mA or less, removable terminal block (4 pins)
• ZONE CONROL OUT: Open collector output, withstand voltage 30 V DC or less, control current: 25 mA or less, removable terminal block (4 pins)
• Chime
• 1-note, 2-note, or ascending, 4-note chime, or None selectable with switch setting
• Indicator
• 5-point LED output level meter, Power LED, LAN connect LED, Priority LED, Emergency LED, Thermal protection LED, Over current protection indicator LED, CPU RUN LED, Error LED, Zone 1 LED, Zone 2 LED
• Operating Temperature
• -10°C to +40°C
• Operating Humidity
• 85 %RH or less (no condensation)
• Finish
• Panel: ABS resin, black
• Case: Surface-treated steel plate, black, paint

Dimension Packaging Weight : 4.0 kg
