FEATURES

• Ultra-low noise discrete MIC preamp with +48V phantom power.
• 8 / 16 mono input channels and 4 stereo input channels.
• Each input channel accepts balanced XLR MIC input and TRS LINE input.
• Low cut for each MIC input.
• Each mono input channel is equipped with 3-band EQ, sweepable MID and PEAK LED.
• 2 stereo input channels accept mono XLR or TRS input; 2 stereo input
• channels accepts RCA input.
• Each stereo input channel is equipped with 4-band EQ and PEAK LED.
• 8 compressor controls and 8 channel insert points.
• AUX 1 & AUX 2 send post/pre-fader signal for monitoring or external effects; AUX 3 & FX send post-fader for internal effects or monitoring.
• PFL/MUTE and 60mm fader for each channel.
• GR1/2, GR3/4 and MAIN L-R buss assignment for each channel.
• MAIN MIX installs a pair of balanced XLR and a pair of unbalanced TRS
• connectors and can be equalized via a 7-band GEQ.
• MAIN MIX supports external effect insert.
• 24-bit DSP processor provides up to 100 effect presets.
• USB player for MP3 playback and recording.
• Switch-mode power supply for 100-240Voltage.
• USB port for MAIN MIX recording or playback through CH 15/16 (M16) or CH 23/24 (M24).
• Cutting-edge and eye-catching design. Uniquely-designed Atmos Meter
• adds extra visual effects to live performance

SPECIFICATIONS

• Noise - Hum & noise :
• Crosstalk - Crosstalk :
• Frequency Response -Mic/Line Input to any output, 20 : Hz-20 kHz <1 dB
• THD + N - Mic sens. -30 dBu, +20 dBu at all outputs @ 1 kHz : <0.006%
• CMRR - Typical @ max gain @ 1 kHz : >80 dB - Typical @ any gain @ 50 Hz : >60 dB
• Input & Output Impedance - Mic Input : 1.8 kO - Line Input : 23.6 kO - Stereo Input : 20 kO - Mix, Aux and Insert Sends : 120 O
• Input & Output Levels - Mic Input max. level : +20 dBu - Line Input max. level : +30 dBu - Stereo Input max. level : +30 dBu - Headphones (@ 200 O) : 150 mW
• Compressor - Gain : 0 - 9 dB - Threshold : 20 dB ?? 5 dB
• USB 2.0 (Standard B) - Inputs / Outputs : 2-in, 2-out - Bit Depth : 16-bit - Sampling rate : 32 kHz / 44.1 kHz / 48 kHz
• USB Player - Inputs / Outputs : 2-in, 2-out - Record sampling rate : 44.1 kHz
• Power - Mains voltage (universal input) : 100 V-240 VAC, 50/60 Hz
• Physical - Net weight : 6.59 kg - Dimensions : 504.62 x 425.00 x 88.34 mm

Dimension Packaging Weight : 7.2 kg
