FEATURES

• Benchmark SuperAnalogue audio performance
• Professional routing and monitoring
• Classic SSL channel processing
• Full-size 100mm faders, Mute–Bus B, PFL
• 12-input summing at mixdown
• Legendary G Series Master Bus Compressor
• Completely balanced signal path
• A superb front end for recording
• Channels 1 and 2 equipped with:
• SuperAnalogue mic preamps with 66dB of gain
• Phantom power; 75Hz highpass filter
• Line-level input, switchable to instrument level
• Newly designed SSL compressor
• Balanced insert points
• Channels 3 and 4 equipped with:
• Line-level stereo inputs with trim
• Master section includes:
• 2 cue buses (sends available on channels 1–4)
• Main and Alt monitor outputs with monitor source matrix, mono check, dim, and cut
• Talkback mic input with phantom power and LMC

SPECIFICATIONS

• Type: Analog Console
• Channels: 6
• Faders: 5 x 100mm
• Inputs - Mic Preamps: 2 x XLR (SuperAnalogue)
• Phantom Power: Yes
• Inputs - Line: 2 x 1/4" (line/Hi-Z), 4 x 1/4" TRS (2 x stereo line), 4 x 1/4" TRS (2 x stereo SuperAnalogue line)
• Outputs - Main: 2 x XLR (main out), 2 x 1/4" TRS (main monitor), 2 x 1/4" TRS (alt monitor)
• Aux Sends: 2 x Cue Sends
• Send/Return I/O: 2 x 1/4" TRS (send L/R), 2 x 1/4" TRS (send L/R), 2 x 1/4" TRS (Bus B out)
• Busses/Groups: 1 x Bus B
• Inserts: 2 x DB-25 In/Out (channel, main)
• Headphones: 1 x 1/4" TRS
• Talkback: 1 x XLR
• EQ Bands: 2-band EQ, Switchable Bell Curve
• Effects: Channel Compressor, G Series Bus Compressor
• Power Source: 5-pin 15V DC Power Supply (included)
• Height: 4.7"
• Width: 10.6" (including trim)
• Depth: 12.2"
• Weight: 7.7 lbs.

Dimension Packaging Weight : 6.6 kg
