FEATURES

• Four SuperAnalogueTM Mic / line / Hi-Z / 48V / HPF and polarity switch
• Four SuperAnalogueTM stereo line level inputs with dual mono switching
• Built in 16 channel 96 Khz / 24-bit USB interface with advanced routing
• Essential version of G-Comp Bus Compressor with 'Auto' release
• 3 Band SSL LF/MF/HF EQ on every channel
• Classic SSL channel dynamics processing
• Listen Mic Compressor
• Dual independent headphone outputs with source matrix
• 100 mm console grade faders
• Professional metering
• Comprehensive monitoring section
• Two stereo cue feeds
• Bus B / Mute switching
• Two fully balanced stereo external inputs
• Up to 18 inputs at mixdown
• Mix Bus inject for cascading additional SiX/BiG SiX

SPECIFICATIONS

• Type: Analog Mixer with USB Interface
• Channels: 18 Inputs (includes summing and inserts), 8 Fader Channels
• Computer Connectivity: USB (16 x 16)
• A/D Resolution: 24-bit/96kHz
• Faders: 9 x 100mm Faders
• Inputs - Mic Preamps: 4 x XLR
• Phantom Power: Yes (per channel)
• Inputs - Line: 8 x 1/4" (4 x stereo channel), 4 x 1/4" (2 x external stereo input)
• Inputs - Other: 4 x 1/4" (Hi-Z)
• Outputs - Main: 2 x 1/4" TRS (main), 2 x 1/4" TRS (main monitor), 2 x 1/4" TRS (alt monitor)
• Aux Sends: 2 x Stereo Cue Send (pre/post)
• Busses/Groups: 2 x 1/4" TRS (Bus B out)
• Inserts: 2 x 1/4" TRS (L/R main bus insert send), 2 x 1/4" TRS (L/R main bus insert return)
• Headphones: 2 x 1/4"
• USB: 1 x USB-C
• Talkback: 1 x XLR
• EQ Bands: 3-band EQ, High/Low Bell Curve, Mid Frequency Shift
• Signal Processing: G-Series Bus Compressor (main mix bus), Channel Compression
• OS Requirements - Mac: OS X 10.14 or later
• OS Requirements - PC: Windows 10 or later (SSL USB ASIO/WDM driver required)
• Rackmountable: Optional rackmount kit (sold separately)
• Power Source: 4-pin 15V DC power supply (included)
• Height: 5.6"
• Width: 19.3" (including trim)
• Depth: 15.4"
• Weight: 15.0 lbs.

Dimension Packaging Weight : 4.2 kg
