FEATURES

• For Active Performers & Actors
• DL4 Waterproof Omni Lavalier Mic (Black)
• Lightweight Bodypack Transmitter
• Digital Predictive Diversity Receiver
• 1760 Auto-Scan Frequencies
• 1/10mW RF Power
• High-Contrast LCD Screens
• Ethernet for Group Scans & Local Control
• Compatible with 8-Hr Rechargeable SB903
• Expandable to 32 Mic Channels/330' Range

SPECIFICATIONS

• System
  - Wireless Transmission : Digital UHF
  - Number of RF Channels : 1760
  - Included Transmitters : 1 x Bodypack with Microphone
  - Diversity : True Digital Diversity
  - RF Frequency Band : H55: 514 to 558 MHz
  - RF Bandwidth : 44 MHz
  - Frequency Step Size : 25 kHz
  - RF Channel Scanning : Auto-Scan
  - Max Operating Range : 328' / 100 m
  - Max Systems per Setup : 32
  - Sample Rate/Resolution : 24-Bit
  - Latency : 3.2 ms
  - Dynamic Range : 120 dBA (Typical)
  - Encryption : None

• Receiver
  - Form Factor : Tabletop / Rackmount
  - Mounting Options : Rackmount, Tabletop (with Included Hardware)
  - Rackmount Size : 1 RU (1/2 Rack)
  - Antenna : 2 x 1/4 Wave External, BNC (Rear-Mount)
  - Number of Audio Channels 1
  - Audio I/O : 1 x XLR 3-Pin Male Balanced Mic/Line Output | 1 x 1/4" TRS Female Balanced Output
  - Gain Range : 0 to +21 dB (3 dB Steps)
  - Pad : 30 dB
  - Audio Output Level : -18 to +42 dB (Balanced, Unbalanced)
  - Phantom Power Protection : On 1/4", XLR Outputs
  - Frequency Response : 20 Hz to 20 kHz +1/-2 dB (Dependent on Mic)
  - Network I/O : 1 x RJ45 (10/100 Mb/s)
  - Network Protocols : DHCP, Manual IP
  - Impedance : 1/4" Output: 1.3 Kilohms (Balanced), 670 Ohms (Unbalanced) | XLR Output: | 400 Ohms (Balanced) | 150 Ohms (Balanced)
  - Adjacent Channel Isolation : >70 dB
  - Spurious : Rejection: >75 dB
  - Power Requirements : AC/DC Power Adapter
  - AC/DC Power Adapter : 15 VDC at 600 mA, Center-Positive (Included)
  - AC Input Power : 100 to 240 VAC, 50 / 60 Hz
  - Display & Indicators : LCD (AF Level, Channel, Frequency, Group, RF Level, Transmitter Battery Status)
  - Housing : Steel
  - Operating Temperature : 0 to 122°F / -17 to 50°C
  - Storage Temperature : -20 to 165°F / -28 to 73°C
  - Dimensions : 7.8 x 1.7 x 6" / 197 x 42 x 152 mm

• Transmitter
  - Form Factor : Bodypack with Microphone
  - RF Output Power : 1 / 10 mW
  - Audio I/O : 1 x TA4/Mini XLR 4-Pin Male Unbalanced Input (Lockable)
  - Auto-Level Control : No
  - Gain Range : 0 +21 dB
  - Sync Method : IR
  - Antenna : 1/4 Wave External, Fixed
  - Power Requirements : Battery
  - Battery Charging Time : 1.25 to 5.5 Hours
  - Approx. Battery Life : 8 Hours (Lithium Shure SB903) | 8 Hours (Alkaline)
  - Display & Indicators : LCD (Battery Status, Channel, Group)
  - Housing : ABS, Plastic
  - Operating Temperature : 0 to 122°F / -17 to 50°C
  - Storage Temperature : -20 to 165°F / -28 to 73°C
  - Dimensions : 2.7 x 3.9 x 1" / 68 x 98 x 25.5 mm
  - Weight : 3.1 oz / 89 g

• Microphone
  - Form Factor : Lavalier
  - Color : Black
  - Sound Field : Mono
  - Capsule : MEMS
  - Polar Pattern : Omnidirectional
  - Frequency Range : 20 Hz to 20 kHz
  - SNR : 63 dB
  - Equivalent Noise Level : 31 dB A-Weighted
  - Maximum SPL : 132 dB SPL
  - Sensitivity : -42.5 dBV/Pa
  - Dynamic Range : 101 dB
  - Output Connectors : 1 x TA4/Mini XLR 4-Pin Female Unbalanced
  - Cable Length : 66" / 1.7 m
  - Operating Voltage : 5 V
  - Operating Current Consumption : 220 µA
  - Length : 0.6" / 14.5 mm
  - Diameter : 0.2" / 5.2 mm
  - Weight : 0.5 oz / 15 g

Dimension Packaging Weight : 12.0 kg
