Technical Specifications
Maximum Sound Pressure Level: 90 dB(A)
RF Output Power: Adaptive up to 250 mW (peak), country-specific
-
Operating Time:
Modulation: GFSK (DECT)
Audio Output Level: –30 dBu to 0 dBu (4 steps)
Battery Specification: Li-Ion, 3.7 V DC
Dynamic Range: > 120 dB(A)
Frequency Band: 1880 – 1930 MHz (country-specific)
Sampling Rate: 24-bit / 48 kHz
Latency: 19 ms
Packaging Weight: 1.2 kg
FEATURES
Very fast setup
Plugs directly into XLR audio input
Ultra compact receiver
Switches on/off by P48 Phantom power
Optimized dynamic range
Auto frequency management
AES 256 encryption
License free
Accessories included for DSLR use
Metal housing
Made in Germany
SPECIFICATIONS
Color : black
Frequency response : 20 Hz - 20000 Hz
THD, total harmonic distortion : typ. 0.1 %
Weight : Receiver: 87 g (incl energy pack)
Audio input : 3,5 mm mini jack
Audio output : XLR
Operating temperature : -10 °C - + 55°C
Signal-to-noise ratio : > 90 dB(A)
RF output power : adaptive up to 250mW (peak) country specific
Operating time : > 4h (Receiver), typ 15 h (Transmitter with LiIon energy pack)
Modulation : GFSK (DECT)
Audio output level : -30 dBu - 0 dBu in 4 Steps
Battery Specification : Li-Ion 3,7 V DC
Dynamic range : > 120 dB(A)
Frequency band : 1880 - 1930 MHz (Country specific)
Sampling rates : 24 bit / 48 kHz
Latency : 19 ms
Dimension Packaging Weight : 1.2 kg
