RM3,120.00 RM2,808.00
SAME DAY DELIVERY / INSTALLATION SERVICE & SELF PICKUP WITHIN KLANG VALLEY / KL AREA - Please select shipping option 'Own... Read more
SKU: COX 12 MKII
SAME DAY DELIVERY / INSTALLATION SERVICE & SELF PICKUP WITHIN KLANG VALLEY / KL AREA
- Please select shipping option 'Own Courier' for same day delivery / self-collect at showroom
- Third party pickup charges to be beared by buyer
- Kindly put a remark for self collection / Lalamove in your order
- installation request (Piano and Drum) which is available within Klang Valley / KL area (Additional Charges)
EAST MALAYSIA ORDERS
- Sea Shipping will be arranged for bulky items, usually takes 3-4 weeks time
FOR STANDARD DELIVERY
Please select shipping option 'Standard Delivery' and all orders will be shipped out on timely manner.
*Kindly take note that the courier services are beyond our control, estimated delivery time is around 2-7 working days
Waze: Live Music Centre
No 20 & 20-1 & 22 & 22A,
Jalan BRP 1/6, Bukit Rahman Putra, 47000 Sungai Buloh, Selangor
Contact : 0-1-6-5-2-0-1-0-6-6
PRODUCT FEATURES
12” woofer (3” VC), 1” PEN compression driver, 2-way coaxial system | 400 W continuous power handling (1,600 W peak) | up to 136 dB SPL | 98 dB sensitivity (1W/1m) | 52 Hz – 20 kHz usable frequency range
Can be used on the floor, standing, suspended or wall mounted | M8 flying points | expandable with SE subwoofer lines | can be powered with SE IA installation and L-Line power amplifiers | speakON® and 4-pin Phoenix connectors | audio signal pass through
Wooden enclosure | polyurea coating | rugged front grille | multifunctional enclosure shape | ergonomic rear handle | 36 mm pole mount
Suitable for installations, bars, stage monitoring, side and front fills, architectural sound and mobile sound applications
SPECIFICATIONS
| Model: | COX 12 MKII |
|---|---|
| ACOUSTICAL | |
| Frequency Response (-3 dB)*: | 134 Hz – 17 kHz |
| Frequency range (-10 dB)*: | 52 Hz – 20 kHz |
| Coverage angles (-6 dB) [H x V]**: | 70° x 74° |
| Coverage angles (-6 dB) [H x V]***: | 96° x 92° |
| Nominal impedance: | 8 O |
| Sensitivity*: | 98 dB |
| Peak power: | 1600 W |
| Continuous power****: | 400 W |
| Maximum Peak SPL*****: | 136 dB |
| System type: | 2-way coaxial system |
| Crossover frequency: | 1.3 kHz |
| Transducers: | Coaxial driver with: LF: 1 x 12 driver (3" voice coil) HF: 1" PEN compression driver (1.7" voice coil) |
| Enclosure type: | Vented box |
| Connectors: | Neutrik speakON® NL4 Phoenix 4-Pin Verbinder MSTB |
| Wiring: | speakON® NL4: Pins 1+ / 1- : Treiber; Pins 2+ / 2- : N.C. Phoenix: Pins 1+ / 1- : Treiber; Pins 2+ / 2- : Link |
| MECHANICAL | |
| Product dimensions [H x W x D] (Including rigging): |
520 x 370 x 350 mm |
| Weight: | 19.5 kg |
| Packaging dimensions [H x W x D]: |
633 x 470 x 450 mm |
| Total weight: | 22 kg |
| Cabinet: | 15 mm plywood |
| Cabinet finishing: | Black polyurea coating |
| Grille: | Powder coated perforated steel |
| Hardware: | 1x rear handle embedded in cabinet 1 x bottom 36 mm socket for pole mounting |
| Rigging: | 5 x M8 for mounting on top and sides 3 x M8 for mounting at the bottom 2 x M8 for mounting on the rear |
| ACCESSORIES | |
| Wall Mounting Bracket | COX12 WB |
| Distanzstange | SPS20 |
| All product specifications are subject to change without notice. | * Full space |
