The B 18 comprises a single 18″ driver mounted in a vented box, with a sophisticated adaptive port that optimises the airflow and improves its response. This technology, developed through exhaustive research, enables a lower cut-off frequency while having smaller volume. This translates into deeper and dynamic bass from a compact enclosure. In addition to the speakON® connectors on the back, the subwoofer includes two additional located on the front. This guarantees wiring flexibility and ease of use, reducing setup time even in large configurations. Finally, the set of accessories specially designed for the B-Line, makes their setup and transportation easier, safer and more comfortable.
Features
The great advantage of powered speakers is the built in amplifier. So there is no need for an external device – the internal amp is optimally matched to the woofer! The B 18A is driven by a mighty 1,600 W (peak) Class-D amplifier. Integrated DSP presets allow loading of preset system setups that are optimally matched to SE AUDIOTECHNIK products. Thus, the entire system is quickly and easily set up and perfectly adjusted. The directivity can be effortlessly changed in a flash from normal to cardioid or end-fire configuration via the large display and the push/rotary controller. Parameters such as EQ, Delay, Sensitivity and Phase can be adjusted and stored in your own User Presets.
SPECIFICATIONS
Model |
B18A |
ACOUSTICAL |
|
Frequency range (-3dB) *: |
34 Hz – 210 Hz |
Frequency range (-6dB) *: |
28 Hz – 260 Hz |
Coverage angles (-6dB) [H x V]: |
Omnidirectional |
Nominal impedance: |
8 Ω |
Sensitivity **: |
0 dB |
Peak power: |
1600 W |
Continuous power ***: |
|
Maximum Peak SPL ****: |
138 dB |
System type: |
1-way self-powered system |
Transducers: |
1 x 18″ driver |
Enclosure type: |
Vented box |
Connectors: |
Input signal: balanced XLR 3-pin female
Link output: balanced XLR 3-pin male
Power input: powerCON® 20A
Power link output: powerCON® 20A
|
Wiring: |
Pin N: Neutral
Pin L: Conductor
Pin E: Ground
|
MECHANICAL |
|
Product dimensions [H x W x D] (Including rigging): |
572 x 542 x 797 mm |
Net weight: |
45 kg |
Packaging dimensions [H x W x D]: |
721 x 615 x 885 mm |
Total weight: |
53 kg |
Cabinet: |
15 – 18 mm plywood |
Cabinet finishing: |
Black or white polyurea coating |
Grille: |
Powder coated perforated steel |
Hardware |
2 SE Audiotechnik® ergonomic handles
4 rubber feet and top recesses for stacking
M20 pole thread
|
Stacking: |
Two-point SE Audiotechnik® stacking system |
ACCESSORIES |
|
Stacking frame for M-F3A PRO: |
B18 SFi M |
Stacking frame for L35: |
B18 SFi L35 |
Pole bar: |
SPS20 |
Transport dolly: |
B18 TD |
Transport cover: |
B18 TC |
Amplifier rain cover: |
P801DL RC |
All product specifications are subject to change without prior notice. |
*** According to EIA-426B Standard (based on RMS Voltage
**** Max Peak SPL = Sensitivity + 10log10(Continuous Power) + 12 dB Crest Factor
|
