| Trim |
Full Set, Top
|
| Colour |
Black, White
|
| SOUND GENERATOR |
PIANO REALITY
|
| MAX POLYPHONY |
256
|
| TONES |
Internal Tones: 305
Tones accessible directly from the piano: 40
Tones accessible only from the Roland Piano App: 265
|
| KEYBOARD |
88 keys (PHA-4 Standard Keyboard: with Escapement and Ivory Feel)
|
| SPEAKER |
(8 x 12 cm) x 2 (with Speaker Box)
-Rated Power Output
12 W x 2
|
| HEADPHONE |
Piano Reality Headphones Ambience
|
| WI-FI & BLUETOOTH |
-Standards
IEEE 802.11b/g/n, 2.4 GHz band
Bluetooth Ver. 5.4
Profile: A2DP (Classic Audio), BAP (LE Audio), GATT (MIDI over Bluetooth Low Energy)
CODEC: SBC, LC3
|
| APP (IOS/ANDROID) |
Piano Sphere
Roland Piano App
|
| DATA PLAYBACK |
-Standard MIDI Files
Standard MIDI Files (Format 0, 1)
-Audio File (requires a USB flash drive, supports USB flash drives of 32 GB or less)
WAV: 44.1 kHz, 16-bit linear format
MP3: 44.1 kHz, 64 k–320 kbps
|
| RECORDER |
-Standard MIDI Files
Standard MIDI Files (Format 0)
Song: 1
Part: 1
Recording capacity per song: approx. 500 KB
|
| INTERNAL SONGS |
4
|
| TUNING, VOICING |
-Touch Sensitivity
Key Touch: 5 steps, fixed touch
|
| EFFECTS |
Ambience: 11 steps
Brilliance: 21 steps
Only for organ tones: Rotary Speaker Effect
-Piano Designer (Settings can be changed only from the Roland Piano App)
Lid
String Resonance
Damper Resonance
Key Off Resonance
Cabinet Resonance
Single Note Tuning
Single Note Volume
Single Note Character
Temperament
Temperament Key
|
| CONVENIENT FUNCTIONS |
Metronome (adjustable Tempo/Beat/Downbeat/Volume/Tone)
Transpose (in semitones)
Dual
Split
Twin Piano
Speaker Switch (Auto, On, Off)
Auto Off
|
| CONNECTORS |
DC In jack
Pedal1 (Damper) jacks: capable of continuous detection when optional pedal connected
Pedal2 (Damper, Sostenuto, Soft) jacks: capable when dedicated pedal board connected
Output (L/Mono, R) jacks: 1/4-inch phone type
USB Mobile/PC port: USB Type-C (R) (supports USB MIDI/Audio and provides power to USB PD (Power Delivery)–compatible smartphones)
USB Memory port: USB A
Phones/Headset jack: Stereo miniature phone type
|
| WEIGHT , DIMENSIONS |
Weight
With music rest attached:
14.0 kg
30 lbs 14 oz
With music rest, dedicated stand KSF-40, and dedicated pedal board KPD-70 attached:
24.1 kg
53 lbs 3 oz
Dimensions
With music rest detached:
1,307 (W) x 332 (D) x 122 (H) mm
51-1/2 (W) x 13-1/8 (D) x 4-13/16 (H) inches
With music rest, dedicated stand KSF-40, and dedicated pedal board KPD-70 attached:
1,307 (W) x 384 (D) x 949 (H) mm
51-1/2 (W) x 15-1/8 (D) x 37-3/8 (H) inches
|
| ACCESSORIES |
Startup Guide
List of operations
Leaflet: "Read Me First"
AC adaptor (PSB-7U）
Power cord
Music rest
Pedal switch (DP-2)
USB 2.0 Type-C (R) to Type-C (R) Cable (1.5 m)
|
