FEATURES
- NEW Next-generation JBL transducers for optimized transient response and enhanced linearity
- NEW Boundary EQ settings compensate for environmentally induced low-frequency anomalies
- Patented Image Control Waveguide for detailed imaging and a wide, room-friendly sweet spot
- Patented Slip Stream low-frequency port for superior bass performance at all playback levels
- Integrated custom Class D amplifiers deliver 112 watts (LF: 56W; HF: 56W) of power for high output and dynamic range
- Frequency response (±3dB): 47Hz–20kHz
- HF Trim switch adjusts high-frequency output to accommodate room acoustics or personal preferences
- Flexible connectivity with balanced XLR and 1/4" TRS inputs, +4dBu/–10dBV input-sensitivity switch, and volume control
- Engineered to JBL Linear Spatial Reference design criteria for outstanding accuracy in any acoustical environment
- Strenuous JBL 100-hour power test ensures years of reliability
- Shielded for safe placement near magnetically sensitive equipment
- Sleek, modern design provides a dramatic flair to any studio
- Compact footprint accommodates a variety of studio spaces
SPECIFICATIONS
- Powered:Yes
- Power Configuration:Bi-amped
- LF Driver Size:6" woofer
- LF Driver Type:Cone
- HF Driver Size:1" tweeter
- HF Driver Type:Soft dome
- LF Driver Power Amp:56W
- HF Driver Power Amp:56W
- Total Power:112W Class D
- Frequency Response:47Hz-20kHz (±3dB), 39Hz-24kHz (-10dB)
- Crossover Frequency:1425Hz
- Maximum Peak SPL:110dB
- Input Types:1 x XLR, 1 x 1/4"
- Enclosure Type:Rear Ported
