FEATURES
- Custom-designed 12-inch woofer
- 2414H compression driver
- Redesigned high-frequency horn
- Power: 1,300W Peak / 650W RMS
- Frequency response: 50 Hz–20 kHz (-10 dB); 60 Hz–20 kHz (-3 dB)
- Max SPL: 127 dB
- Dispersion: 100° H x 60° V
- Audio I/Os: 2 XLR Combo, 1 XLR passthrough
- Advanced dbx DSP: Automatic Feedback Suppression, ducking, 100ms speaker delay, parametric EQ
- Built-in 3-channel digital mixer
- Backlit color LCD screen provides easy access to functions
- Universal JBL Pro Connect app control
- Bluetooth 5.0 streaming and control
- Durable polypropylene cabinet and metal grille
- Two ergonomic handles simplify transport
- Built-in pole mount and optional EON700 Universal Yoke Mount expand system configuration options
- Stackable cabinets allow easy storage
SPECIFICATIONS
- System Type : 12IN Powered Loudspeaker
- Woofer Model : 712G
- Woofer Size : 12"
- Woofer Magnet : Ferrite
- Woofer Voice Coil : 2"
- Tweeter Model : 2414H Compression Driver
- Tweeter Size : 1''
- Tweeter Magnet : Neodymium
- Transducer Impedence : LF 4ohm rated, HF 8ohm rated
- Max SPL : 127dB @1m/4Pi
- Freq Range -10 : 50Hz - 20kHz
- Freq Range -3 : 60Hz - 20kHz
- Hor Dispersion : 100°
- Vert Dispersion : 60°
- Power Rating : 1300W peak / 650 RMS
- AC power input : 100V-120V or 220V-240V
- Cooling : Passive
- LED indicators : 1 Power LED, 1 Limit LED, 1 Front LED, 2 Signal/SSM LEDs
- Input Impedance : 50k/100k un-balanced/balanced
- Input Gain : -?to +36db
- Crossover Frequency : 2 kHz
- I/O : 2 XLR Combo Jacks / BT | 1 XLR M Thru
- Cabinet : PP+10% Talc
- Grille : 16GA perforated steel with acoustically transparent black cloth backing
- Suspension / Mounting : 4 M10 Suspension points, 36mm Pole Socket, universal yoke bracket holes
- Handles : 2, cable channel on bottom
- Net Weight : 14.6kg (32.19 lbs.)
- Gross Weight : 18.4kg (40.57 lbs.)
Dimension Packaging Weight : 26.4 kg
