GoWireless boasts a massive 100MHz bandwidth, unmatched in its class. With Channel A spanning 470MHz to 520MHz and Channel B covering 530MHz to 580MHz, users have an abundance of frequency choices for optimal performance. This wide spectrum allows GoWireless to effortlessly navigate crowded UHF environments, avoiding interference and ensuring a clean signal. The 100MHz bandwidth also supports the simultaneous operation of up to 20 units (ideal environment and with optional antenna distributors for better antenna and cable management), making it ideal for large-scale events. Flexible transmitters synchronization with either Channel A or B simplifies management in complex setups.
SPECIFICATIONS:
• Main Frame Size: EIA Standard 1U
• Receiving Channel: Two channels
• Receiving Mode: Non Diversity
• Frequency Stability: ±0.003%
• Carrier Frequency Range: 470 MHz – 520 MHz for CH A, 530 MHz – 580 MHz for CH B
• Total Frequency Channel: 2 x 100 CH
• Oscillation: PLL Synthesis
• Sensitivity: >105 dB
• Bandwidth: 100 MHz
• Max. Deviation Range: ±48 kHz
• S/N: >103 dB (1 kHz @ A)
• T.H.D: <0.4 @ 1 kHz
• Frequency Response: 45 Hz ~ 18 kHz ±3 dB
• Transmitter Transmission Strength: 30 mW for handheld & bodypack
• Spurious Emission: >55 dBc
• Operating Distance: 60 meters in line of sight & low RF noise environment
• Antenna Interface: 2 x BNC
• Audio Interface: 6.3 mm unbalanced audio output, XLR balanced audio output
• Max. Unit Stacking: 16 transmitters in low RF noise environments
• Power Supply: 12 ~ 18 VDC
• Battery: AA 1.5V for handheld & bodypack
• Battery Life: ~6 hours for handheld & bodypack
• Power Consumption: 120 mA for handheld & bodypack
• LCD Display: Frequency, CH, Battery, RF, AF, MUTE for Receiver; Frequency, CH, Battery for Handheld & Bodypack
• Dimensions (WxDxH): 420 x 180 x 44 mm
• Weight: 2.2 kg
• Packaging Dimensions (WxDxH): 515 x 78 x 394 mm
• Packaging Weight: 3.8 kg
