iLoud Micro Monitor Pro makes critical mixing possible in the studio, at home or on the go. The evolution of the ubiquitous iLoud Micro Monitor is designed to provide reference presentation, transparency and impressive accuracy that can be placed anywhere or carried with you.
With the same ARC room calibration and control software as iLoud MTM MKII and flagship Precision models, Micro Monitor Pro allows you to experience uncoloured, quality audio monitoring in any space, from acoustically treated rooms to spaces definitely not designed for audio work.
Features:
- Ultra-compact format for tight spaces and travel
- 109 dB maximum peak SPL at 1 meter for clear, powerful sound
- Flat and transparent frequency response for critical listening
- iLoud physics-defying bass down to 50 Hz
- Advanced DSP for perfect transient response and linear phase
- Built-in ARC self-calibration adjusts to any space
- Controllable with X-MONITOR software for custom tuning
- Ideal as a secondary reference in large studios
- Tilting feet plus threaded insert for precise positioning
Specifications
| Type |
2-way bi-amped, digitally controlled compact studio monitor |
| LF Driver |
3? composite cellulose fibre, custom-made mid-woofer |
| HF Driver |
1? low-distortion silk-dome tweeter |
| Acoustic Design |
DSP-tuned bass reflex |
| Amplifier type |
High-efficiency Class-D |
| Total Power |
50 W RMS |
| LF Power |
30 W RMS |
| HF Power |
20 W RMS |
| Crossover Type |
Digital, Linear Phase |
| Crossover Frequency |
2.5 kHz |
| Frequency Response |
50 Hz to 20 kHz ± 2dB, 42 Hz to 22 kHz @ -10dB |
| Phase Response |
System remains coherent within +/- 30° from 500 Hz to 20 kHz |
| Sensitivity (XLR) |
-10 dBu signal generates 90 dB SPL @ 1 m |
| Sensitivity (RCA) |
-22 dBu signal generates 90 dB SPL @ 1m |
| Continuous Max. SPL |
94 dB (free field, one speaker, 1 m distance, ANSI-2034 weighted pink noise) |
| Peak SPL |
107.3 dB (free field, one speaker, 1 m distance, ANSI-2034 weighted pink noise) |
| Peak SPL |
109.3 dB (half space, one speaker, 1 m distance, ANSI-2034 weighted pink noise) |
| Placement setup |
Manual switches for LF Extension, LF trim, HF trim, Desk position |
| LF Extension Switch |
Sets -3 dB point of the frequency response at 50 or 80 Hz (LFE) |
| LF Switch |
Low shelf, +2 dB or -3 dB from 100 Hz down |
| HF Switch |
High shelf, +2 dB or -2 dB from 8 kHz up |
| Desk Switch |
-3 dB at 250 Hz and +4 dB at 1.2 kHz |
| Calibration |
Fully automatic and built-in digital calibration |
| Total Latency (TOF) |
3.00 ms |
| Connectors |
1 x XLR balanced input, 1 x RCA unbalanced input, 1 x USB type-C, C8 power socket |
| Power requirement |
90 to 240 V AC, auto-ranging, 50 or 60 Hz, 1 A max |
| System Requirements |
macOS® 10.15 or newer (macOS 11 or newer required for Apple Silicon Processors), Intel® Core i5 Processor or equivalent/newer |
| Includes |
One pair - iLoud Micro Monitor Pro speaker, Power cord, USB-A to USB-C cable, 1.5 m (4.92 ft), One - ARC Microphone, One - ARC Microphone clamp |
| Dimensions |
106 mm (4.17?) x 206 mm (8.11?) x 158 mm (6.22?) |
| Weight |
1.37 kg (3.02 lb.) |
