FEATURES
• Groundbreaking Shotgun Microphone with Integrated Wireless Module
• Support Wired/Wireless Dual Modes for One-button Switch
• 48kHz/24bit Super Cardioid Recording, Broadcasting-level Sound Quality
• Digital/Analog Output, Universal for Camera, Smartphone, Computer
• Intelligent Auto-sensing 3.5mm Output and Power Switch
• 75/150Hz Two Low-cut Filter Modes, High-frequency Boost
• Support Gain Control, Safety Mode, Real-time Monitor and Muting
• OLED Screen for Monitoring and Visual Operation
• Built-in Rechargeable Lithium Battery, Support Charging While Using
• Battery Life Up to 38H in Wired Mode, Up to 14H in Wireless Mode
• Low Latency<20ms, Wireless Working Range Up to 100m (Open Area)
• Full Metal Material, Super-shielding, Stable and Durable
Specificatons
|
Wireless Band
|
2400~ 2483.5MHz
|
|
Transmitting Power
|
+10dBm
|
|
Receiving Sensitivity
|
-86dBm
|
|
Antenna
|
Transmitter:Ceramic Antenna
Receiver:PCB Antenna
|
|
Sound Delay
|
<20ms
|
|
Polar Pattern
|
Super Cardioid
|
|
Frequency Response
|
20Hz~20kHz
|
|
Low-cut
|
75Hz,150Hz
|
|
High-frequency Boost
|
10kHz
|
|
Output Impedance
|
50Ω
|
|
Sensitivity
|
-38dB ~ -18dB re 1V/Pa(12mv ~ 125mv @ 94dB SPL) ±2dB @ 1kHz
|
|
S/N
|
75dB SPL(A-weighted,as per IEC651)
|
|
Equivalent Noise
|
19dB SPL(A-weighted,as per IEC651)
|
|
Maximum SPL
|
130dB SPL(@ 1% THD)
|
|
Dynamic Range
|
111dB SPL(A-weighted,as per IEC651)
|
|
Analog Output
|
3.5mm TRRS,TRS
|
|
Digital Output
|
USB-C 48kHz 24bit
|
|
Battery
|
Transmitter:Li-polymer 3.7V 350mAh
Receiver:Li-polymer 3.7V 330mAh
|
|
Battery Life
|
Wired Mode: 50 Hours for 3.5mm Devices; 8 Hours for XLR Devices
Wireless Mode: 7 Hours
|
|
Dimensions
|
Transmitter:Φ22mm x L210mm
Receiver:39 x 22 x 55mm
|
|
Net Weight
|
Transmitter:93g
Receiver:29g
|
|
Operating Temperature
|
0℃ ~ 50℃
|
|
Storage Temperature
|
-20℃ ~ 60℃
|
