Features:
• 48kHz/24bit Record, Broadcasting-level Sound Quality • 25mm Cardioid Condenser Mic, Accurately Pickup • Mini and Lightweight, External Dual XLR Interfaces • Support 3.5mm/XLR Multi Interfaces for 5V/48V Mic Input
• Revolutionary CalMixTM Denoise Algorithm,Two-stage Denoise Mode • Internal Bluetooth 5.3 Chipset, Advanced Bluetooth Connection • Support Individual Mic Preamps, Monitor Volume and Output Gain Control • Adjustable 3 EQ Modes, 3 Reverb Modes and 5 Voice Effects • 6 Sound Pads to Create Live and Podcast Atmosphere • Support One-click Loopback/Duck/Mute and Monitoring • Internal Pop Filter and Capsule Shock Mounting • Built-in Rechargeable Lithium Battery, Operating Time Up to7 Hours • Touch-sensitive Panel Design, Flexible and Visible Operation
Specification
|
Interface
|
|
Input Interface
|
1 x USB-C to 2 x XLR, 2 x 3.5mm
|
|
AUX Input Interface
|
1 x 3.5mm, 1 x Bluetooth
|
|
Digital Interface
|
1 x USB-C
|
|
OUT Interface
|
2 x 3.5mm
|
|
SPK Output Interface
|
1 x 3.5mm
|
|
Headphone Output Interface
|
2 x 3.5mm
|
|
Audio Resolution
|
|
Sampling Rate
|
48kHz
|
|
Bit Depth
|
24bit
|
|
Microphone Input
|
|
Dynamic Range
|
100dB(A-weighted,as per IEC651)
|
|
Frequency Response
|
20Hz ~ 20kHz, ±0.1dB
|
|
THD+N
|
0.003%, 1kHz, -3dBFS, 22Hz/22kHz BPF
|
|
Equivalent Noise
|
-128dBu(A-weighted,as per IEC651)
|
|
Input Impedance
|
5kΩ
|
|
Microphone Input Maximum Level
|
-8dBu
|
|
Preamp Gain Range
|
10dB ~ 60dB
|
|
SPK Output
|
|
Dynamic Range
|
100dB(A-weighted,as per IEC651)
|
|
Frequency Response
|
20Hz ~ 20kHz, ±1dB
|
|
Output Impedance
|
600Ω
|
|
Microphone Output Maximum Level
|
4dBu
|
|
Headphone Output
|
|
Dynamic Range
|
100dB(A-weighted,as per IEC651)
|
|
Frequency Response
|
20Hz ~ 20kHz, ±1dB
|
|
Output Impedance
|
6Ω
|
|
Microphone Output Maximum Level
|
4dBu
|
|
Others
|
|
Battery
|
Polymer Lithium Battery 1800mAh 3.7V
|
|
Operating Time
|
With Phantom Power On: 4 Hours; With Phantom Power Off: 7 Hours
|
|
Charging Specification
|
USB-C 5V2A
|
|
Phantom Power Output
|
48V
|
|
Net Weight
|
303g
|
|
Dimension
|
31 x 110 x 184mm
|
|
Working Temperature
|
0℃ ~ 50℃
|
|
Storage Temperature
|
-20℃ ~ 60℃
|
