The AP41 Performance Series Guitar Wireless System from Audix includes the R41 1-channel diversity receiver and B60 bodypack transmitter with a 30" guitar cable. The R41 diversity receiver operates on a wide-spectrum frequency range of 522 to 554 MHz MHz and offers one-touch auto scan searches for clear channel. Thanks to the one-touch sync function, this receiver easily links to the B60 bodypack transmitter placed within 300'.
Additionally, the bodypack transmitter can be connected to guitars and instruments using the included 3-pin mini XLR to 1/4" cable. This durable and low-profile aluminum bodypack can be securely clipped onto the guitar strap or clothing. The refined circuitry of the transmitter allows for precise and accurate reproduction of guitar and bass without compromise.
Incorporate up to 16 systems to use 16 unique channels simultaneously
Single-channel receiver supports one wireless microphone
32 MHz wide spectrum tuning
106 pre-coordinated frequencies
High-contrast LCD shows RF and AF signal strength, group/channel/frequency, level/squelch, battery level, and more
One-touch sync via infrared
One-touch scan eliminates inefficient manual tuning
Ground-lift switch helps eliminate ground loops or hum
Metal strain relief for power cable
Adjustable AF and RF level
Selectable lock function prevents the transmitter from being accidentally muted or powered off
| Frequency Band |
522 to 554 MHz |
| Bandwidth |
32 MHz |
| # Of Simultaneous Systems |
Up to 16 |
| Switchable Frequencies |
106 pre-coordinated frequencies |
| Wireless Range |
Up to 300' / 91 m |
| Antenna Connector |
2 x BNC (8 VDC, 150 mA) |
| Outputs |
1 x XLR 3-pin balanced
1 x 1/4" TS unbalanced |
| Audio Output Level |
XLR: -12 dBV at 25 kHz deviation, 600-Ohm load, +6 gain
1/4": -18 dBV at 25 kHz deviation, 10-Ohm load, +6 gain |
| Audio Level Control |
-12 to +9 dB in 3 dB steps |
| Frequency Response |
45 Hz to 18 kHz |
| Compander |
2:1 |
| Pilot Tone |
32 kHz |
| Receiving System |
Single tuner, antenna diversity |
| Signal to Noise Ratio |
105 dB at 30 kHz deviation (A-weighted) |
| Total Harmonic Distortion (THD) |
≤0.7% (33 kHz deviation at 1 kHz) |
| Sensitivity |
5 dBµV (S/N 60 dB at 25 kHz deviation, A-weighted) |
| Power Requirement |
100 to 240 VAC, 50/60 Hz, 12 VDC, 1 A |
| Dimensions |
8.1 x 8.1 x 1.7" / 205 x 206 x 44 mm |
| Weight |
1.9 lb / 0.9 kg |
Audix B60 Performance Series Bodypack Transmitter (522 To 586 MHz) Specs
| RF Power Output |
10/30 mW |
| Bandwidth |
64 MHz |
| Gain Adjustment |
0 dB, -6 dB, -12 dB, -24 dB |
| Inputs |
1 x mini-XLR 3-pin |
| Input Impedance |
Mic: 10 kOhms
Line: 1 MOhm |
| Maximum SPL |
Approximately 128 to 140 dB (depending on microphone) |
| Battery Life |
Approximately 14 hours |
| Current Consumption |
110 mA typical |
| Power Requirement |
2 x AA 1.5 V batteries |
| Dimensions |
2.6 x 3.5 x 0.7" / 67 x 90 x 17 mm |
| Weight |
3 oz / 85 g without batteries |
Packaging Info
| Package Weight |
0.66 lb |
| Box Dimensions (LxWxH) |
11.45 x 4.75 x 2.8" |
