FEATURES

• 6 Dual stereo inputs, 2 with mic inputs, RIAA preamps for up to 4 turntables.
• 2 auxiliary sends selectable pre/post fader (and crossfader).
• MIDI output from VCF 1+2, crossfader, LFO (MIDI clock), dedicated data control and start/stop button.
• New twin-rail VCA channel faders or high quality VCA rotary faders.
• 2 independent stereo mix outputs.
• 2 VCF filters - any performance channel can be assigned to either filter and either side of crossfader.
• 2 x independent Low Frequency Oscillators (LFO) for filter modulation.
• Active Penny & Giles VCA crossfader allowing contour to be set from smooth to scratch mix.
• Custom illumination showing status of all performance switches.
• 4 band EQ - high definition of frequency bands, with 'infinite kill' on HF and LF; wide Q for cut, narrow Q for boost.
• Dedicated booth output.
• Metering - extensive channel, output and cue metering.
• Intelligent cue system allowing pre or post EQ monitoring.
• Monitor section - includes post EQ switch; split cue and Cue/Mix monitor balance control.
• 2 x headphone outputs 1/4" and 3.5mm jack.
• Talkover facility on mono/mic channel attenuates music by 20dB.
• Dedicated clean feed record output.
• Input selectors with 2 colour indicators.
• Smooth action level controls.
• MIDI output from VCF 1+2, crossfader, LFO 2 (MIDI clock), dedicated data control and start/stop button.
• Large 'light-pipe' illuminated cue switches.
• 9 led 3 colour channel 'bulls eye' LED meters.
• Either smooth travel 60mm VCA faders or rotary VCA faders (Linear or Rotary versions).
• 2 Independent mix outputs.
• 2 Rotary master level controls.
• Dual stereo analogue VCF effects.
• 3 Filter modes combine for more effects.
• Independent frequency sweep controls.
• Resonance control for subtle or wild effects.
• Filter LFO Depth and tempo controls.
• Illuminated Filter switches punch effect in or out.
• Powerful headphones monitor with auto cue.
• Headphones split cue and Aux 1 & 2 monitoring.
• Stereo music only booth monitor output.
• Booth mono and mute switching.
• 9 led 3 colour main 'bulls eye' LED meters.
• Balanced 0dBu XLR stereo Mix 1 output.
• Impedance balanced Line stereo Mix 2 output.
• Pre-fade recording output.
• Universal power supply for worldwide performance.
• Internal installer options for system optimization.

SPECIFICATIONS

• Channels:4 + 2 mic/stereo return
• MIDI Control:Crossfader, LFO (MIDI clock), dedicated data control and start/stop button
• Effects:X-FX engine plus 2 x LFO
• Analog Inputs:4 x stereo RCA phono, 4 x stereo RCA line, 2 x XLR mic, 4 x 1/4" return
• Analog Outputs:2 x XLR, 4 x TRS, 1 x stereo RCA
• Headphones:2 x 1/4"
• MIDI I/O:Out
• Other I/O:2 x TRS sends with 4 x TRS returns on mic 1 and mic 2 channels
• Faders:60mm VCA channel faders
• Crossfader:Replaceable active Penny & Giles VCA crossfader with adjustable contour
• EQs:4-band with infinite kills
• Rackmountable:Yes
• Height:3.5"
• Width:12.6"
• Depth:14"
• Weight:13 lbs.

Dimension Packaging Weight : 11.4 kg
