FEATURES

• 19" Rackmountable mixer with 8 XLR/TRS mic/line inputs
• 100mm faders
• 2 Dual Stereo inputs with separate gain and 'On' switches
• 4-band EQ with 2 sweepable mids
• 6 reconfigurable Aux sends - 2 x pre fade, 2 x switched, 2 x post fade
• 2 stereo returns
• Dedicated mono output fader
• Independent A/B output
• Twin FX engines
• Lamp socket
• USB multitrack recording option (USB card sold separately)
• Footswitch connector for muting/unmuting the ST1 FX return

SPECIFICATIONS

• Type:Analog
• Channels:12
• Computer Connectivity:Optional USB expansion card
• Faders:12 x 100mm
• Inputs - Mic Preamps:8 x XLR
• Phantom Power:8
• Inputs - Line:8 x TRS
• Inputs - Other:2 x Stereo (4 x TRS)
• Outputs - Main:2 x XLR (Main), 1 x XLR (Main Mono)
• Outputs - Direct:8 x TRS
• Outputs - Other:2 x TRS (A, B Out)
• Aux Sends:2 x Pre, 2 x Pre/Post, 2 x Post
• Send/Return I/O:6 x TRS (Aux Out), 2 x Stereo
• Channel Inserts:Yes
• Headphones:1 x 1/4"
• Talkback:Yes
• EQ Bands:4-band, 2 x Sweepable Mids
• Effects:Yes
• Rackmountable:Yes
• Height:7.7"
• Width:20"
• Depth:20.9"
• Weight:24 lbs.

Dimension Packaging Weight : 25.2 kg
