The CQ-20B is an ultra-compact digital audio mixer designed to be operated via its built-in WiFi or through connection to a wired or wireless network. The processing engine, utilising Allen & Heath’s acclaimed FPGA technology, brings numerous time-saving tools to the CQ to speed up and simplify common tasks for users of all abilities. Gain Assistant automatically sets preamp gain to the optimal level and monitors and adjusts for any unexpected peaks in the signal. Feedback Assistant identifies and filters out problem frequencies across all outputs via simple one-button operation, with more in-depth control available for challengiWith the DX88-P 8x8 96kHz Remote Control Expander Rack, you can seamlessly enhance your audio setup. This device offers eight inputs and eight outputs on Phoenix/Euroblock connectors, making it an ideal solution for fixed installations. It's a straightforward way to add local or remote expansion to AHM Audio Matrix Processors.
The DX88-P features eight mic/line inputs with a generous +60dB of gain, phantom power, and a -20dB pad. Additionally, it provides eight line outputs, all on Phoenix/Euroblock connectors. This device is designed for maximum flexibility, allowing you to position it up to 100m away from the mixer.
SPECIFICATIONS
Compatibility: Allen & Heath SQ Digital Mixers / AHM Audio Matrix Processors / Avantis Digital Mixers / dLive Digital Mixers
Input Sensitivity: -60 to +15 dBu
Gain: +5 to +60 dB (1 dB Steps)
Pad: -20 dB
Maximum Input Level: +30 dBu (Pad In)
Maximum Output Level: +21 dBu
Input Impedance: >4 kΩ (Pad Out), >10 kΩ (Pad In)
Output Impedance: <75 Ω
EIN: -127 dB (With 150 Ohm Source)
Inputs / Outputs: 8x Block 3-Pin Line/Mic Input, 8x Block 3-Pin Line Output
Power Source: AC Adapter with Power Brick (Included)
DC Input Power: 12 VDC at 3.3 A
Power Consumption: 39.6 W
Operating Current: 3.3 A
Operating Temperature: 32 to 104 °F (0 to 40 °C)
Color: Black
Mounting: Side: 1x Optional Rackmount
Material: Metal
Dimensions: 8.5 x 7.7 x 1.7" (21.6 x 19.6 x 4.3 cm)
Weight: 3.33 lbs (1.51 kg)
