FEATURES

• Expressive GHS variably weighted keys are heavier in the low notes, lighter in the high notes, mimicking acoustic piano play
• Motion Control Synthesis unifies and controls AWM2 and FM-X sound engines
• 256-note total polyphony: 128-note stereo AWM2 + 128-note FM-X
• Super Knob controls multiple parameters simultaneously for highly expressive sound interaction
• Send 10/receive 4 audio channels plus 16 channels of MIDI via a single USB cable
• Live Sets allow Performance organization without copying, renaming, or changing order
• 4-Part Seamless Sound Switching: change Performances while holding notes without sound or effect cutoff
• Direct Control Assignment assigns controls at the touch of a button
• The A/D input processes external audio sources with your instrument’s DSP
• Motion Sequences drive synthesizer parameters through rhythmic control data you can interact with in real time
• Envelope Follower allows internal or external audio to be used as a synth parameter control source
• AWM2 provides data compression without sacrificing sound quality
• MODX OS expands composition and performance potential, newly adding Voices, Live Sets, and more
• 1.75GB internal flash memory lets you install your own samples and external libraries for a completely personalized sound set
• FM-X 8-operator FM synthesis delivers amazingly dynamic sonics and complex sound design
• Virtual Circuitry Modeling (VCM) re-creates the sound and behavior of vintage effects and signal processors
• Sidechain automatically controls dynamic behavior of parts separately from one another
• Vocoder effect re-creates classic voice-synth sounds
• Rhythm Pattern for effortless addition of drums or percussion to any Performance
• USB-to-host allows audio/MIDI connectivity to your USB-equipped computer or iOS device
• USB-to-device port allows connection of USB flash drives for loading and storing data
• Advanced Integration with Mac/PC

SPECIFICATIONS

• Type:Keyboard Synth
• Sound Engine:AWM2, FM-X
• Analog/Digital:Digital
• Number of Keys:88
• Type of Keys:GHS Weighted, Graded Hammer Action
• Velocity Sensitive:Yes
• Other Controllers:Pitchbend, Mod wheel, Super Knob
• Polyphony:128 Note Stereo AWM2, 128 Note FM-X, 16-part Multitimbral
• Number of Presets:2,227 x performances
• Filter:18 types
• Effects Types:Reverb, Delay, Chorus, Flanger, Phaser, Tremolo/Rotary, Distortion, Compressor, Wah, Lo-Fi
• Arpeggiator:8 Simultaneous Parts, 10,239 Presets
• Sequencer:16-track, 128 patterns, 128 songs
• Memory:1.75GB internal flash memory
• Audio Inputs:2 x 1/4" A/D (L/mono, R)
• Audio Outputs:2 x 1/4" (L/mono, R)
• Headphones:1 x 1/4"
• USB:1 x Type B (host), 1 x Type A (device)
• MIDI I/O:In/Out/USB
• Pedal Inputs:2 x 1/4" (control), 1 x 1/4" (sustain), 1 x 1/4" (assignable)
• Power Source:12V DC power supply (included)
• Height:6.3"
• Width:52.5"
• Depth:15.9"
• Weight:30.4 lbs.

Dimension Packaging Weight : 35.0 kg
