WHARFEDALE PRO FOCUS 12 Series 500 Watts RMS 12" 2-Way Passive Loudspeaker - Each / Pair (FOCUS12/FOCUS-12)

Description

The two-way Focus 12 and Focus 15 models employ High-Q 100° x 10° long-throw waveguide horn geometry to project the sound to the back of large listening areas. All this comes together to create a point-source array system!



Key Features

●12″ passive loudspeaker

  • Dual angle 35mm pole socket

  • 3.0″ voice coil LF driver

  • 3.2″ voice coil HF driver

  • 500 watts AES (RMS)

  • 1000 watts Programme

  • 2000 watts Peak

  • 133 dB Max SPL @ 1 meter



SPECIFICATIONS







Model Name

Focus-12

System Type

Passive

Configuration

Two-way

Frequency Response (+/-3 dB)

60 Hz – 20 KHz

Frequency Range (-10 dB)

55 Hz – 20 KHz

Sensitivity (2.83 v / 1 m)

99.5 dB

Calculated Maximum SPL @1 m

133 dB

System Rated Impedance

8 Ω

Low Frequency Transducer



Size

331 mm / 12″

Voice Coil Size

76.2 mm / 3″

Rated Impedance

8 Ω

LF Power (re:AES2-2012)

500 w

High Frequency Transducer



HF Driver Type

Compression Driver

Voice Coil Size

81 mm / 3.2″

Exit Size

35.5 mm / 1.3″

Diaphragm Material

Titanium

Rated Impedance

8 Ω

HF Power (re:AES2-2012)

75 w

Nominal Coverage (H x V)

100° x 10°

Power



System Continuous Power

500 w

System Programme Power

1000 w

System Peak Power

2000 w

Crossover frequency

1.6 KHz

Input Connector

2 x NL4

(speakON Compatible)

Hardware



Pole Mount

Dual-angle

35 mm Pole Socket

Handles

2 On Sides

Enclosure



Enclosure Material

15 mm Plywood

Finish

Black Rhino Paint

Grille Material & Finish

1.5 mm Steel

Dimensions – (Unpacked)



Height

625 mm / 24.6″

Width Front

455 mm / 17.91″

Width Rear

270 mm / 10.63″

Depth

435 mm / 17.13″

Dimensions – (Packed)



Height

695 mm / 27.36″

Width Front

455 mm / 17.91″

Width Rear

270 mm / 10.63″

Depth

426 mm / 16.78″

Weight



Net Weight

26.3 kg / 57.9 lbs

Gross Weight

28.2 kg / 62.04 lbs
