Next Audio AD500 4x125W matrix amplifier with DSP ( AD-500 / AD 500 )

Description

Product Type: Class D Amplifier with DSP
Frequency Response: 20Hz - 20kHz (+0 / -0.25dB)
Amplifier Technology: UMAC Class D - Full Bandwidth PWM Modulator With Ultra-Low Distortion
Number of Amplifier Channels: 4 Channels Low Impedance (LoZ) / 2 Channels High Impedance (HiZ)
Amplifier Power - Stereo 8?: 4 x 125W
Amplifier Power - Stereo 4?: 4 x 125W
Amplifier Power - 100V: 2 x 250W
Amplifier Power - 70V: 2 x 250W
Speaker Output: 4? - 16? | 70V | 100V
Zones Output: 4-Zones Output
THD+N: <0.05% (20Hz-20kHz, 8? load, 3dB below rated power)
SNR (Signal to Noise Ratio): >106dB (A-weighted, 20Hz-20kHz, 8? load)
Output Voltage: 70Vp / 140Vpp (unloaded) | Bridged 140Vp / 280 Vpp (unloaded)
DSP Technology: Ultimate DSP with WI-FI and Ethernet Connection
DSP Adjustable Parameters: Filters: PEQ, FIR, hi/lo-shelving, all-pass, band-pass, hi/lo-pass | Limiters: RMS Voltage, Peak Voltage | GPIO Functions | Routing
DSP Presets: Allows to Store and Load Individual Presets as well as Preset Libraries
Delay Adjustment: 100ms (34.3m) per Output
Control Type: Controlled Via Webpage - Compatible with Desktop, Tablet and Mobile Phone (Wireless or Cable 1 x RJ45)
Wireless Connection System: Works as a WI-FI Access Point (WAP) or WI-FI Client
Audio Signal Inputs: 4 x Analog Unbalanced Inputs | 4 x Analog Balanced Inputs | Stereo S/PDIF
Input Connectors: 4 x RCA | 2 x 6-Pole 3.5mm Phoenix Type | 1 x RCA | 8 x GPIO
Audio Signal Outputs: Stereo S/PDIF
Output Connectors: 1 x RCA | 8 x GPIO
Speakers Output Connectors: 2 x 4-Pole 5mm Phoenix Type
Protections: Short Circuit, DC, Undervoltage, Temperature and Overload Protection
Operating Temperature Range: 0ºC - 40ºC
Cooling Type: Speed Controlled Fan
Power Supply: UREC Universal Mains Switch Mode Power Supply (SMPS) with Power Factor Correction (PFC) and Standby Converter
Power Input: AC 100V - 240V 50Hz/60Hz
Mains Connector: Standard IEC socket
Power Consumption: 150W
Special Features: GPIO Functions: Standby, Mute, Volume Control, Trigger IN, Trigger OUT
Dimensions (WxHxD): 44 x 220 x 319mm (1.7 x 8.7 x 12.6 in)
Fixation: 1U 19" Rack Mount | Wall / Desktop Mount (Necessary Accessories Not Included)
Net Weight: 2.8kg (6.2 lbs)
Shipping Weight: 3.5kg (7.7 lbs)
Accessories: 19" Rack Mount Kit | Wall / Desktop Mount Kit (not included)

Next Audio AD500 4x125W matrix amplifier with DSP ( AD-500 / AD 500 )

Product form

RM8,763.00

SKU: AD500

    Description

    Product Type: Class D Amplifier with DSP
    Frequency Response: 20Hz - 20kHz (+0 / -0.25dB)
    Amplifier Technology: UMAC Class D - Full Bandwidth PWM Modulator With Ultra-Low Distortion
    Number of Amplifier Channels: 4 Channels Low Impedance (LoZ) / 2 Channels High Impedance (HiZ)
    Amplifier Power - Stereo 8?: 4 x 125W
    Amplifier Power - Stereo 4?: 4 x 125W
    Amplifier Power - 100V: 2 x 250W
    Amplifier Power - 70V: 2 x 250W
    Speaker Output: 4? - 16? | 70V | 100V
    Zones Output: 4-Zones Output
    THD+N: <0.05% (20Hz-20kHz, 8? load, 3dB below rated power)
    SNR (Signal to Noise Ratio): >106dB (A-weighted, 20Hz-20kHz, 8? load)
    Output Voltage: 70Vp / 140Vpp (unloaded) | Bridged 140Vp / 280 Vpp (unloaded)
    DSP Technology: Ultimate DSP with WI-FI and Ethernet Connection
    DSP Adjustable Parameters: Filters: PEQ, FIR, hi/lo-shelving, all-pass, band-pass, hi/lo-pass | Limiters: RMS Voltage, Peak Voltage | GPIO Functions | Routing
    DSP Presets: Allows to Store and Load Individual Presets as well as Preset Libraries
    Delay Adjustment: 100ms (34.3m) per Output
    Control Type: Controlled Via Webpage - Compatible with Desktop, Tablet and Mobile Phone (Wireless or Cable 1 x RJ45)
    Wireless Connection System: Works as a WI-FI Access Point (WAP) or WI-FI Client
    Audio Signal Inputs: 4 x Analog Unbalanced Inputs | 4 x Analog Balanced Inputs | Stereo S/PDIF
    Input Connectors: 4 x RCA | 2 x 6-Pole 3.5mm Phoenix Type | 1 x RCA | 8 x GPIO
    Audio Signal Outputs: Stereo S/PDIF
    Output Connectors: 1 x RCA | 8 x GPIO
    Speakers Output Connectors: 2 x 4-Pole 5mm Phoenix Type
    Protections: Short Circuit, DC, Undervoltage, Temperature and Overload Protection
    Operating Temperature Range: 0ºC - 40ºC
    Cooling Type: Speed Controlled Fan
    Power Supply: UREC Universal Mains Switch Mode Power Supply (SMPS) with Power Factor Correction (PFC) and Standby Converter
    Power Input: AC 100V - 240V 50Hz/60Hz
    Mains Connector: Standard IEC socket
    Power Consumption: 150W
    Special Features: GPIO Functions: Standby, Mute, Volume Control, Trigger IN, Trigger OUT
    Dimensions (WxHxD): 44 x 220 x 319mm (1.7 x 8.7 x 12.6 in)
    Fixation: 1U 19" Rack Mount | Wall / Desktop Mount (Necessary Accessories Not Included)
    Net Weight: 2.8kg (6.2 lbs)
    Shipping Weight: 3.5kg (7.7 lbs)
    Accessories: 19" Rack Mount Kit | Wall / Desktop Mount Kit (not included)
