FEATURES
- Premium 12-inch low frequency driver with a 2 ½ inch diameter edge-wound ribbon voice coil for solid and extended bass, high efficiency and power handling
- JBL 2412 1-inch ferro-fluid cooled compression driver with titanium diaphragm delivers clean and warm high notes and uncompromised reliability
- JBL SonicGuard™ technology constantly protects the high frequency driver from excessive power
- Precision-crafted crossover feeds drivers with clear-cut frequencies and delivers coherent summation in the crossover region
- Progressive Transition™ waveguide provides superior coverage control, reduced distortion and smoother frequency response
- Rugged enclosure made from 15mm MDF (Medium Density Fiberboard)
- 36-mm dual angle pole-mounting socket
- Dent-resistant grille protects the internal from damage on the move or during the show
SPECIFICATIONS
- System Type : 12” 2-way stage monitor
- Frequency Range (-10dB) : 60 Hz – 16 kHz
- Frequency Response (±3 dB) : 70 Hz – 12 kHz
- Sensitivity : 99 dB SPL
- Nominal Impedance : 8 ?
- Power Capacity : 250 watts
- Peak Power Capacity : 1000 watts
- Recommended Amplifier Power : 250 - 500 watts @ 8?
- Maximum SPL (1m) : 129 dB
- Crossover Frequency : 1.8 kHz
- Coverage : 90° × 50°
- Dimensions (H x W x D) : 567 mm × 381 mm × 323 mm (22.3 in × 15.0 in × 12.7 in)
- Net Weight : 16.7 kg (36.8 lbs)
- Shipping Weight : 20.3 kg (44.8 lbs)
- HF Driver : JBL 2412 1” exit compression driver mounted on Progressive TransitionTM Waveguide
- LF Driver : JBL M112-8
- Input Connector : Neutrik Speakon® NL-4 (×1)?1/4” TS phone jack (×1); parallel
- ENCLOSURE CONSTRUCTION : 15 mm (0.6 in) MDF (Medium Density Fiberboard) with glued and mechanically fastened joint detail; black painting.
- Grille : 18-gauge, powder-coated steel
- Mounting & Suspension : 36 mm, dual-angle pole-mount socket; 9×M10 suspension points
Dimension Packaging Weight : 17.0 kg
