Players everywhere love the GX-100 for its streamlined design, free-flowing interface, and high-quality tones. Armed with the core GX-100 engine, the compact GX-10 brings you the same inspiring experience in an even more portable footprint. You get loads of AIRD amps and effects for covering every style, plus speedy sound building with the intuitive color touch display and panel knobs. Adding in multi-mode footswitches, an integrated expression pedal, and USB audio connectivity, the GX-10 seamlessly transitions from nightly stage performing to desktop recording, song creation, and daily practice sessions.
Specs
Power
- Power supply: AC adaptor
- Current draw: 600 mA
- Power consumption when in off mode: 0.0 W
Connectivity
- Connectors: Input jack, Output (L/Mono, R) jacks, Send jack, Return jack — 1/4-inch phone type, Phones jack — Stereo 1/4-inch phone type, CTL2,3/EXP2 jack — 1/4-inch TRS phone type, USB Computer port — USB Type-C, Bluetooth Adaptor connector — Dedicated connector, DC In jack
- Input impedance: Input — 1 M ohm, Return — 1 M ohm
- Output impedance: Output (L/Mono, R) — 1 k ohm, Phones — 44 ohms, Send — 1 k ohm
- Recommended load impedance: Output (L/Mono, R) — 10 k ohms or greater, Phones — 44 ohms or greater, Send — 10 k ohms or greater
Controls
- Controls: Down switch, Up switch, CTL1 switch, Power switch, EXP1 switch, Page button, Menu button, Effects button, Exit button, Write button, 1-4 knobs, Select knob, Output Level knob, EXP1 pedal
- Display: Color Graphic LCD (480 x 272 dots) Touch screen
- Effects: 170 types
- Maximum number of effects: 15+3 (Divider/Mixer, Send/Return, Phrase Loop)
- Memories: 198 (User) + 99 (Preset)
- Phrase loop: 38 sec. (Mono), 19 sec. (Stereo)
- Tuner internal detection: +/-0.1 cent
Construction
- Sampling frequency: 48 kHz
- AD conversion: 24 bits + AF method (Adaptive Focus method)
- DA conversion: 32 bits
- Processing: 32-bit floating point
- Frequency response: 20Hz – 20kHz ± 1dB
- Dynamic range: Max. 127dB (digital to analog)
- Nominal input level: Input — -10 dBu, Return — -10 dBu
- Maximum input level: Input — +7 dBu, Return — +7 dBu
- Nominal output level: Output (L/Mono, R) — -10 dBu, Phones — -10 dBu, Send — -10 dBu
- Output level: Output — -11.76 dBu (Nominal); 26.25 dBu (Max), FX Loop Send — -17.78 dBu (Nominal); 14.5 dBu (Max), Headphones — -7.4 dBu (Nominal); 18.3 dBu (Max)
- Impulse response/IR processing: Supports 24-bit/44.1kHz mono WAV files, 1024 and 2048 points; supports up to 50 user IRs
- Dimensions: 11-13/16 (W) x 7-3/16 (D) x 2-15/16 (H) inches
- Maximum height: 11-13/16 (W) x 7-3/16 (D) x 3-3/4 (H) inches
- Weight: 4 lbs 14 oz
Accessories
- AC adaptor (PSB-1U + AC Cord Set)
- Owner's manual
- Leaflet "Using the Unit Safely"
Options (sold separately)
- Footswitch: FS-5U, FS-5L, FS-6, FS-7
- Expression pedal: EV-30, FV-500L, FV-500H, Roland EV-5
- Bluetooth audio MIDI dual adaptor (Model BT-DUAL)
- Wireless MIDI expression pedal: EV-1-WL
- Wireless foot switch: FS-1-WL
