FEATURES
Ghost mic preamps deliver phenomenal performance
Dual Lexicon effects engines provide you with studio-grade effects
Limiters from dbx keep your levels under control
4-band British EQs with 2 sweepable mid-bands for musical sound-shaping
Highpass filters and 48V phantom power on all channels
Switchable hi-Z inputs for guitars, bass, and other instruments
3 aux busses, 2 aux/FX buses, and flexible pre/post switching
4 mono/2 stereo subgroups with routing switches
2-in/2-out USB connectivity for playback and recording (24-bit/48kHz)
Comprehensive Soundcraft GB-series audio routing
Robust tour-grade metal housing for durability
SPECIFICATIONS
Type:Analog
Channels:22
Computer Connectivity:USB (2 x 2)
Faders:25 x 100mm Throw
Inputs - Mic Preamps:16 x XLR
Phantom Power:22
Inputs - Line:20 x TRS
Inputs - Other:1 x Stereo (RCA)
Outputs - Main:2 x XLR
Outputs - Other:5 x TRS (Aux), 4 x TRS (Subgroup), 1 x TRS (Footswitch)
Aux Sends:5 x Pre/Post
Busses/Groups:3 x Aux Busses, 2 x Aux/FX Busses, 4 x Mono Subgroups, 2 x Stereo Subgroups
Headphones:1 x 1/4"
USB:1 x Type A, 1 x Type B
EQ Bands:4-band (British)
Effects:Yes
Height:4.3"
Width:19"
Depth:26"
Weight:24.4 lbs.
Dimension Packaging Weight : 19.8 kg
